| US$69,999.00 | 1 Set (MOQ) |
Parameter | Value | Notes |
Length of the Roller(mm) | 2800 | |
Power of Double Roller(kw) | 15kw X 2 | AC Servo induction motor |
Power of Single Roller(kw) | 15kw X 2 | AC Servo induction motor |
Power of Screw Feed(kw) | 11kw | AC Servo induction motor |
Power of Rotary Clipper(kw) | 5.5kw | AC Servo induction motor |
Power of Rubber roller (kw) | 5.5kw | AC induction motors |
Total Power(Kw) | 82kw | |
Roller Reducer | Helical Gear Reductor X 4 | R87 |
Screw Feed Reducer | Helical Gear Reductor X 1 | R87 |
Veneer output speed(m/min) | 50-80 m/min Adjustable 50-80 m/min | |
Blade (mm) | 2700*180*16 | |
Screw Diameter(mm) | 90mm | |
Max opening(mm) | 520 | |
Minimum Log core | 32mm | |
Thickness(mm) | 0.8 - 4.0 | |
Clipper width(mm) | >= 400 mm | |
Control Unit | Peeling Speed Adjust System Closed loop Servo control | PLC + Touch Screen PLC+ MD810 |
Size(mm) | 6000*2300*1600 Length()*Width()*Height() | |
Weight(kg) | 11500 |
Parameter | Value | Notes |
Length of the Roller(mm) | 2800 | |
Power of Double Roller(kw) | 11kw X 2 | AC induction motor |
Power of Single Roller(kw) | 11kw X 2 | Siemens AC induction motor |
Power of Oil Pump(kw) | 7.5kw | AC induction motor |
Total Power(Kw) | 51.5kw | |
Max opening(mm) | 600 | |
Weight(kg) | 8000 | |
Else |
Parameter | Value | Notes |
Lendth of the Veneer (mm) | 2600 mm | |
Width of the Veneer (mm) | 500 - 1270 mm | |
Thickness of the Veneer (mm) | 0.8 - 4.0 mm | |
Stacking speed (m/min) | 80m/min | |
Stacking height(mm) | 800 - 1000mm | |
Number of the Deck | 1 | |
Classify of the veneer | 2 | , Two levels:wastage, first level veneer |
Power of the Vacuum Fan | 3kw X 5 | |
Total Power(Kw) | 26kw | |
Control Unit | PLC + Touch Screen Inverter Driver for all the motors | |
Weight(kg) | 4500kg |
| DESCRIPTION | UNIT | PARAMETER |
| LENGTH OF ROLLER | MM | 1500 |
| SINGLE ROLLER POWER | KW | 7.5KW *2 |
| DOUBLE ROLLER POWER | KW | 7.5KW *2 |
| FEEDING POWER | KW | 7.5KW SERVO |
| CUTTER POWER | KW | 2.2KW SERVO |
| RUBBER ROLLER POWER | KW | 2.2KW |
| GEARBOX | HELICAL GEARBOX*4 | |
| PEELING SPEED | M/MIN | 50-80 |
| PEELING THICKNESS | MM | 0.4-4 |
| BLADE SIZE | MM | 1500*180*16 |
| SCREW SIZE | MM | 90 |
| MAX OPENING | 500 | |
| LOG CORE | 35 | |
| CUTTING SIZE | MM | ≥400 |
| CONTROL SYSTEM | PLC+TOUCH SCREEN CLOSED LOOP SERVO CONTROL | |
| OVERALL SIZE | MM | 4500*2200*1500 |
| WEIGHT | KGS | 6300 |
| high inovance 810 advanced serve drive system, shorten acceleration time and less brake time. use xinjie high speed XD series PLC and touch screen, shorten running time approach switch is imported autonics, stable singal, and response speed fast. 50-80M/MIN peeling and cutting together, all motors are controller by servo drives, frequency speed adjustment, save power, strong anti-voltage fluctuation. imported encoder, don't loss speed, which has strong anti-interference capability. double rail guide, machine is thicken steel plate, running stable Roller sides with encoders, detecting speed and electricity. | ||
| DESCRIPTION | UNIT | PARAMETER |
| LENGTH OF LOG | MM | 1300 |
| DIAMETER OF LOG | MM | Ø100-600 |
| BLADE SIZE | MM | 1500*180*16 |
| ROLLER LENGTH | MM | 1500 |
| HYDRAULIC POWER | KW | 5.5 |
| ROLLER POWER | KW | 11KW*2 |
| GEARBOX | 350*2 | |
| WEIGHT | KGS | 5400 |
| OVERALL SZIE | MM | 4500*2200*2400 |
| FUNCTION | PEEL BARK, CHIP FUNCTION NO NEED FOUNDATION, WITH BASE AND EASY WASTE CLEAR | |
| DESCRIPTION | UNIT | PARAMETER |
| VENEER WIDTH | MM | 1300 |
| VENEER LENGTH | MM | 400-1300 |
| LIFTING TYPE | HYDRAULIC LIFT | |
| FORMAT VENEER CONVEY | CHIAN AUTO CONVEY | |
| SPEED | ADJUSTABLE | |
| VENEER THICKNESS | MM | 1-4 |
| POWER | KW | 32.4 |
| STACKING HEIGHT | MM | 1200 |
| WASTE VENEER CONVEY | HAVE | |
| OVERALL SIZE | MM | 12000*3300*2500 |
| WEIGHT | KGS | 4000KGS |
