Product Details
Product Description
Product Description
Brand:ABB
Type:AX722F 3BDH000377R0001
Origin: the Swiss
Warranty: 365 days
Colour: new/used
Shipping method: Courier delivery
Spare parts spare parts, the main DCS control system of PLC system and the robot system spare parts,
Brand advantage: Allen Bradley, BentlyNevada, ABB, Emerson Ovation, Honeywell DCS, Rockwell ICS Triplex, FOXBORO, Schneider PLC, GE Fanuc, Motorola, HIMA, TRICONEX, Prosoft etc. Various kinds of imported industrial parts
Calculations 1. Calculate the current requirements for each bus (ModuleBus and CEX-Bus). Be sure not to exceed the limits given in Table 132 on page 407. Data relating to TB820, TB840, CI801 and CI840 is accessible from the S800 I/O documentation. 2. Calculate the current consumption at 24 V, for each electrical ModuleBus, by adding: Im = I (24 V) + I (5 V) x 0.3 3. To calculate the requirement for a specific power supply unit, total the results of the 24V current consumption calculations, as follows: Itot = Im1 + Im2 + .... + Iunits Table 131 + ICI801s + ICI840s + ITB820s + ITB840s If redundant CPUs are used, current for both CPUs must be included.
Recommended Components All recommended components listed below were successfully utilized during exhaustive tests made by ABB, prior to launching the AC 800M Controller. Table 134. Recommended Components – PROFIBUS DP Component Description PROFIBUS DP Due to the large selection of commercially available equipment manufactured to PROFIBUS DP Standard, there is no recommendation for specific PROFIBUS DP components. For further details refer to PROFIBUS DP Web Site.
PROFIBUS DP/PA Linking Device (LD 800P) LD 800P performs the following tasks: • Potential separation between the PROFIBUS DP and the PROFIBUS PA • Conversion of the RS 485 physical arrangement of the PROFIBUS DP to the physical arrangement based on IEC 61158-2 of the PROFIBUS PA. • Adapting the PROFIBUS DP transfer rate to the PROFIBUS PA transfer rate of 31.25 kBd. • Power supply of PROFIBUS PA stations over the bus line. • Diagnostics via LEDs. • Ensuring intrinsic safety if the PL 890 power link module with an intrinsically safe interface is used. A PROFIBUS DP master (class 1 master), which organizes the exchange of process data, is contained in the controller (PLC/PCS). Moreover, a configuration tool, usually a PC, can be connected as class 2 master to the PROFIBUS DP. Parameterization and configuration of the bus elements usually takes place by means of this configuration tool - even during operation. This is performed using the acyclic channel of the PROFIBUS DP or PROFIBUS PA. LD 800P supports both cyclic as well as acyclic PROFIBUS communication
>>
