Super-Above 5ton Hydraulic Crawler Excavator with 0.5 Cbm Bucket with High Quality Engine

Product Description

Product Description

Super-above 5Ton Hydraulic Crawler Excavator for Sale
Super-above hydraulic excavator subject to full hydraulic drive has been widely used throughout China and exported to
more than twenty countries and regions in the world by virtue of its high working efficiency like medium-sized excavators
and such characteristics of less fuel consumption and higher flexibility.
Performance Characteristics:
* Imported Cummis engine is powerful ,low noise,energy efficient.
* Advanced energy-saving Kawasaki hydraulic system provides good controllability and high efficiency;
* Customized Super-above exclusive engine can meet Euro stage IV Emission Standard. 2. Multiple applications
* Different boom, arm and bucket combinations can provide excellent all-around versatility.
* Multi-functional work tool system can meet various operational requirements including digging, breaking and so on.
3. Comfortable operating experience * Air conditioner and heater ensure the appropriate temperature.
* Air-suspension seat equipped with electric heating function. * Integrated control panel and large display screen provide
multiple information.
Optional configuration: break hammer and pipeline.quick coupler,rotary driller,hydraulic vibrating tamper are available.
Specification Super-above 6 ton mini excavator small digger.
SUPER-ABOVE 6tons excavator adopts a good engine excellent in environmental protection and energy saving.
Moreover, it uses a load sensitive hydraulic system, able to guarantee operator's better controlling of the machine
and better movement coordination, reduce the demand for operation proficiency of the driver; in addition, the reliability
of this system has been recognized by the majority of users.
The stress analysis and structure optimization of such key components platforms, swing arms, bucket rods and lower
chassis has fully guaranteed the reliability of the structural members.
The daily maintenance is sufficiently convenient and you only need to open the rear hood for maintenance of the engine oil, fuel and air filters.
* More energy efficient and environmental protection
Adopt new type environmental protection Yanmar engine which has the features of low speed, large torque, low fuel consumption,
high operating efficiency, reliability and durability. Adopt large displacement main pump with large low and high pressure-withstanding value,
which can guarantee that the machine has smooth operation and high digging efficiency.
* More reliable and durable
Optimize the design of boom and arm and further strengthen the key positions to make them more wear resisting and secure.
Bucket teeth are installed with cross pin, which can effectively prevent the toothed sleeve from falling off and thus can improve the service life.
* More comfortable and safe
Humanized detail design, all the control components inside the cab are arranged scientifically and reasonably
according to ergonomics theory. Cup holder, standby power, magazine bag, storage box and other humanized configurations are added
to improve the convenience and comfort of operation to the most extent.
Specification

Operation Weight		5010 kg
Bucket Capacity		0.23 m ³
Main performance	Travel speed(H/L)	4.2/2.2 km/h
	Rotating speed	10 r/min
	Gradeability	35°
	Ground pressure	32.5 kPa
	Bucket digging force	48.3 kN
	Arm digging force	32.5 kN
	Maximum traction	50.5 kN
Hydraulic system	Rated flow of main pump	151.2 L/min
	Pressure of prime valve	24.5 Mpa
	Pressure of travel system	22 Mpa
	Pressure of swing system	21 Mpa
	Pressure of pilot system	3.5 Mpa
Oil capacity	Fuel tank capacity	110 L
	Hydraulic tank capacity	85 L
	Engine oil capacity	12 L
Appearance size	Overall dimensions(L*W*H)	5860×1920×2585 mm
	Width of platform	1780mm
	Width of crawler	400 mm
	Clearance under counterweight	700 mm
	Min. ground clearance	385 mm
	Min. tail swing radius	2890 mm
Working scope	Max. digging height	5630 mm
	Max. dumping height	3945 mm
	Max. digging depth	3830 mm
	Max. vertical wall digging depth	2680 mm
	Max. digging reach	6130 mm
	Min. swing radius	2460 mm
Standard	Boom length	3000 mm
	Arm length	1600 mm
	Bucket Capacity	0.23 m ³

Product Show
Features& Applications
The widened track shoes guarantee low ground pressure, high stability, and powerful traction to fulfill precise
horizontal operations.
The wet type steering clutch and brake can prolong the service life and are interlinked with each other toguarantee
the rapid and flexible steering controls by joysticks.
It can complete the digging, handling, and landfill operations of earthworks and is suitable for the engineering
constructionsfor roads, farms, water conservancy projects, municipal projects, and energy projects.

---
