US$900.00-1,500.00
|
24 Pieces
(MOQ)
|
Basic Info.
Braking Mode
Front and Rear Disc Brakes
Cooling Method
Air Cooling
Engine
150cc, 200cc, 250cc, 400cc
Fr. Shock
Upright or Inverted Type Are Optional
Muffler
Many Styles to Choose From
Transport Package
Frame+Carton
Production Capacity
20000 Units Per Year
Product Description
OPTIONS:
1, This model can use 150cc, 200cc and 250cc single cylinder air-cooled (or oil-cooled) balance shaft engines, and can also use 400cc water-cooled two cylinder engines.
2, The Front shock absorber have normal type or invertd type. Their front disc brake, stem steering and handlebar will also change accordingly.
3, EFI, ABS and Remotr control are optional.
If you interested any of our model or have any question, please do not hesitate to contact us.
Technical specifications:
| Engine | Frame |
| Engine model | 165FMM balance shaft | Dimension | 2080*790*1100mm |
| Cylinder | Single | Wheel Base | 1410mm |
| Valve | 4-stroke | Dry weight | 147 kg |
| Cooling Type | Air-cooling | Max. load | 160 kg |
| Bore* Stroke | 65.5 * 66.2mm | Max. speed | 115km/h |
| Displacement | 223.4ml | Clutch type | Manual |
| Starter | Electrical | Brake (Fr./Rr.) | Disc/Disc |
| Ignition | Transistor | Transmission | Chain |
| Rated power | 11.5 Kw 7500±500 r/min | Wheel | Alloy |
| Max. Torque | 17N.m 5500±500 r/min | Tire | 110/70-17, 140/70-17 |
| Package | CBU/SKD | CKD |
| Packing status | Carton with iron bracket | Carton with wooden bracket |
| Packing size | 1950*560*860mm | |
| Qty in container | 24/20GP, 48/40GP, 72/40HQ | |
| M.O.Q | 24 units | |
DETAILS:
How to get the exact price:
1, Please tell us the details that affect the price, such as the displacement and type of engine you need, the state of front shock absorber, etc.
2, Do you have any special requirements for the product to meet the local market, such as remote control, Bluetooth, MP3 and so on?
3, The price has a great relationship with the order quantity, so please tell us the quantity you need to order when making an inquiry.
4, In order to ensure the interests of importers, but also to ensure the best after-sales service. Our company doesn't do retail business.
1, Sub-assembly - VIN code printed on frame and pressed steel bowl.
2, Assembly line operation.
3, Comprehensive performance test of motorcycle.
4, Product packaging assembly line operation.
1, Finished product warehouse CKD packaging.
2, Product transportation - CKD loading.
3, Finished product warehouse - SKD packaging.
4, Product transportation - SKD loading.
1, Indonesian President and his wife drove our products to visit his people.
2, Paraguayan Vice President Test Drive Our Tricycle.
3, Russian OTTC experts visited our factory and test drove our electric vehicles.
4, European TUV experts come to our factory for inspection and technical exchange.
1, Photos of the Canton Fair.
2, Interview with local motorcycle media in Sao Paulo, Brazil.
3, New motorcycle made its debut in Russia.
4, Vietnam Electric Vehicle Exhibition.
>>
