Commercial Stainless Steel Horizontal Centrifugal Cooking Oil Filter Machine

Product Description

https://winglobal-machinery.en.made-in-china.com/product/kGzrujIvXMhP/China-Spiral-Oil-Expeller-Rapeseed-Peanut-Oil-Press-Machine.html
Product Description
centrifugal oil filter separate pure oil from the heavier gluish
phospholipid matter and other impure sludge through the employment of high speed rotating drum which produces strong centrifugal force,as a result clear oil will come out from the outlet after each stop. here are its main strengths:
1. easy operation: each filter movement lasts 8 min for about 35kg,after each 350kg oil processing a sludge-removal is needed.
2. no filter cloth needed: no need to clean up the filter cloth and with no wearable parts,super economical.
3. energy saving: machine will cut power after 2 min on-power,inertia force will do the rest of separation work,thus reducing your power bills.
4. to efficiently remove phospholipid matter from crude oil,that it gives no froth when heated,delivering better tastes.
5. fitted with shock resistant device,with much stabler operation.

Product Parameters
Standard Technical Parameters of Centrifugal Oil Filter:

Model		90
Dimensions(MM)		550x880x1000
Hourly Capacity(KG)		250
Power (KW)		three phase grade 4
Processing Each Time (kg)		32
Total Weight (KG)		185

Operation guidance:
1. Prior to usage,it is recommended crude oil temperature be kept at between 60°-80°C,and salt water with a concentration of 5%,temperature between 90°-100°C,amount 1.5%-2% that of the crude oil weight. At first,blend the mixture evenly for 2-5 min,and leave it to settle for 5 min. Second,initiate the centrifugal oil filter,add the crude oil. The oil filter,after powered on for 2 min,will disconnect spontaneously. Wait till the filter stops,finished oil will discharge automatically. Note that at first trial the filter might not perform to its peak due to lower tempera-ture,as it will be consummated when temperature is maintained.
2. After the filtration the finished oil should look clear and lucid,if otherwise it suggests either an excess or inade-quacy of the salt water added. If in excess,moisture content will exceed tolerance that the oil looks turbid,less water should be added next; as for the latter case,when there is not adequate water,the phospholipids matters in the oil can not be fully removed so that there will be deposits,consider increasing your water input.
Machine Disassembly:
To dismantle the bearings,remove the cap,oil distributor tray,rator drum by order (note: the fixture screw hole of the rotor drum shall not be displaced with the lower hole),then the damper connecting screw,the stainless steel frame and the motor to be placed upside down on the ground,rid the V blet,use a wheel plugger to take off the belt wheel on the main shaft,then the snap rings underneath it,use a hammer to strike down on the main shaft,the contact position padded with a wood plank with a thickness 2-5cm to avoid shaft damage. After the main shaft dettached,the belt wheel bearing is left on the machine frame. Invert the frame and pad the base for 5-10cm,beat down the bearing. Should the rotor bearing remains on the frame,strike it towards the opposite direction to remove it. Whereas if it is stuck on the shaft,use two crowbars to pry it,if not smooth you can beat it with a ha-mmer to help. If the bearings run on shortage of oil with the absence of big noise,you can clean it with diesel or gasoline,and lub it with premium quality oil,and put it back in the reverse order aforementioned. If it is with big noise,you need to change for new bearings,50# 6212 two sets,60# 6212 two sets.
Company Profile
Henan Winglobal Machinery a fully integreated factory enterprise of design, manufacturing and sales of oil presses. It is designated by the former Ministry of Industrial Machinery as the recognised oil press manufacturing base, with 40 years history till now.We are proud of our sophisticated equipment and rich technical expertise. Guided by the principle of "Dependable Quality, Reasonable Price, Timely Delivery, Considerate Aftersales", we have established firm and ever growing relationships with customers both at home and abroad.We passed ISO in 2000, and in 2008 we achieved CE certificate. With our strength, our oil press products come with less energy consumption, and best oil yield rate. The oil press can be used to squeeze oil from all types of granular or powder oil seeds, including soybean, peanut, sunflower seeds, tung seeds, mustard seeds, castor seeds, palm fruit, palm kernel/fibre, coconut, rapeseeds, moringa etc.Apart from the above, we also manufacture the combined automatic oil press, auxiliaries of all sorts, palm oil processing complete line, oil refinery set and so on.
Why Choose us
Decent price
Quick delivery
Durable quality
We are honored to cooperate with your respectable business anytime!
FAQ
Q: Can you help chose suitable products?
A: Yes. We have many experts who have worked in this field for many years. They can help you select the most suitable products according to your actual condition. And they can design proper process flow based on your special situation. If necessary, we can even send professionals to your local place for site planning and work-flow design.
Q: How about the quality of your products?
A:We put the quality in the first place based on the honesty. Our machines are manufactured strictly according to national and international standards, and we take a test on each equipment before the delivery. You can also use Trade Assurance for product quality protection, punctual shipment protection and payment protection.
Q: How about the price?
A: We pursue small profits but quick turnover, and we can give you lower price than other trading companies. If the product is really suitable and can benefit you, the price is negotiable.
Q: If I don't know how to operate this machine? How can I do?
A: Our machine has been tested OK and fully assembled before.
A: Shipping, customer just needs to make2~4 hours wear-in and then can work.
Q:Can I use the machine to extract several kinds of raw materials?
A:Yes, sure, as sesame, sunflower, peanut, coconut, soybean, ect.

---
