| Model | BCH-800 |
| Drilling Dia. (mm) | 140-400 |
| Drilling Depth (m) | 700 |
| Power Head Stroke (m) | 6.6 |
| Driving Speed (km/h) | 2.5 |
| Climbing Capacity | 30 |
| Main Power (kw) | 150 |
| Working Pressure (Mpa) | 1.7-3.5 |
| Air Consumption (m3/min) | 17-42 |
| Drill Pipe Dia. (mm) | 102/108/114 |
| Drill Pipe Length (m) | 1.5/2.0/3.0/6.0 |
| Lift Force (T) | 30 |
| Rotating Speed (RPM) | 55-120 |
| Rotating Torque (N.m) | 8850-13150 |
| Dimension (L*W*H)(m) | 6.3*2.3*2.95 |
| Weight (Ton) | 13 |
