Hmc50 4 Axis CNC Horizontal Milling Machine Machining Center with Direct Drive Spindle Head

US$50,000.00-300,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
HMC-50
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools
Movement Method
Contour Control
Control Method
Closed-Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.01~0.02(mm)
Performance Classification
Economical CNC Machine Tools
Certification
GS, CE, RoHS, ISO 9001
Condition
New
Product Name
Hmc50 4 Axis CNC Horizontal Milling Machine machine
Applicable Industries
Building Material Shops, Manufacturing Plant
Marketing Type
Direct Markteing / Distributor
Video Outgoing-Inspection
Provided
Core Components
System /Spindle/Ballscrew
Tool Magazine Capacity
40t
Type
Horizontal Machining Center
Delivery Time
in Stock
Table Size
630*630
Exported Country
Russia, Germany, American, Indian, SA, Pk
Spindle Rpm
6000rpm
Screw
NSK/Hiwin
Control System
Fanuc, GSK, Simens, Mitsubishi, Hnc
Atc
30, 40, 60
Main Motor
15/18.5kw
Transport Package
Suitable for Sea Shipping
Specification
3400x5300x2600
Trademark
SK
Origin
Nanjing China
HS Code
8457101000
Production Capacity
300 Sets/Year

Product Description

Hmc50 4 Axis CNC Horizontal Milling Machine Machining Center with Direct Drive Spindle Head
1.1 DESCRIPTION
1.2 FEATURE

Classic column moving structure, the overall base is rigid enough, oil-water separation structure. The side layout of the manipulator tool magazine is isolated and protected, and the tool change is fast and reliable. The X-direction guide cover has a large inclination angle, double-sided spiral + chain rear chip removal, and the chip removal is smoother. Three-axis heavy-duty roller linear guide, good acceleration performance, suitable for high-efficiency processing. Spindle configuration with high rigidity, wide-area high-torque spindle motor, strong re-cutting capability. Full-featured, flexible configuration, convenient expansion, to meet different customer requirements. Fully servo-driven dual-pallet exchange device, the movement is smoother and more stable.
1.3 PARAMETERS

Specification Unit HMC50 HMC63 HMC80 HMC100 HMC125
X/Y/Z axis mm 660/580/620 1050/750/900 1300/1000/1000 1600/1000/1400 2000x1300x1400
Distance from spindle end to
workbench centre		 mm 130-750 150-1050 200-1200 250-1650 350-1750
Distance from spindle centre to
workbench surface		 mm 100-680 100-850 120-1120 120-1120 120-1420
Workbench size(L*W) mm 500x500 630×630 800x800 1000x1000 1250x1250
Max. workbench load Kg 700 1200 2000 2200 3500
Workbench divisions mm 1°/0.001° 1°/0.001° 1°/0.001° 1°/0.001° 1°/0.001°
Max. workpiece turning diameter on
workbench		 mm 800 1400 2000 2200 2600
T-slot(number - width -spacing) Mm 5-18-100 5-22-125 5-22-160 5-22-200 7-22-160
Spindle tapered bore (type / installed size) mm BT40 BT50 BT50 BT50 BT50
Spindle speed rpm 8000 6000 6000 6000 60000
X/Y/Z axis rapid feed m/min 34/34/34 30/30/30 24/24/24 24/24/24 18/18/18
Maximum cutting feed mm/min 10000 10000 10000 10000 10000
Tool change method Knife arm type Knife arm type Knife arm type Knife arm type Knife arm type
Toolholder specifications type BT40 BT50 BT50 BT50 BT50
Tool capacity tools 24
Disc-type		 30
Disc-type		 30
Disc-type		 30
Disc-type		 30
Disc-type
Max tool length - Φ80 Φ115 Φ115 Φ115 Φ115
Max tool dia mm 300 350 350 350 350
Max. tool weight kg 8 18 18 18 18
Fastest tool change time (T-T) sec 2.5 5 5 5 5
Spindle motor kw 11/15 15/18.5 15/18.5 15/18.5 15/18.5
XYZ Positioning accuracy mm 0.008 0.008 0.008 0.01/0.01/0.008 0.012/0.08/0.08
XYZ Repositioning accuracy mm 0.005 0.005 0.005 0.008/0.008/0.005 0.006/0.005/0.005
Worktable Positioning accuracy
1°/0.001°		 mm 5"(8")
 5"(8")
 5"(8")
 5"(8")
 5"(8")
Worktable
Repositioning accuracy
1°/0.001°		 mm 3"(5")
 3"(5")
 3"(5")
 3"(5")
 3"(5")
Machine size:L*W*H mm 2600x3300x2600 3400/5300×2900 4500x6000×4000 4900x6500x4000 6000x7000x4500
Machine.Weight approx. t 8 12.5 16.5 20 27

1.4 STANDARD ACCESSORIES
1 30 tool magazines 6 Tri-color warning light 11 Rigid tapping 16 Portable chip blowing air gun
2 Workpiece Cooling System
Spindle cooling		 7 Machine cleaning water gun 12 Fully enclosed protective cover 17 Large flow chip flushing device
3 Automatic lubrication system 8 Spindle output water 13 Foundation screws and pads 18 Spindle nose labyrinth dust blower
4 Spindle air curtain dustproof system 9 Electric cabinet heat exchanger 14 Tools and Toolboxes 19 Oil filter
5 Working light 10 Network transmission and CF card function 15 Double helix cutter and chain plate cutter 20 Transformer
