Cast Basalt Composite Pipeline Of Dust Removal System

Product Details

Product Description

Product Description
Cast basalt composite pipeline of dust removal system are used too many industrial areas where the abrasive, chemical and hot materials transported and which are commonly lined steel elbows. Cast basalt composite pipeline of dust removal system is composed of steel pipe tee, cast basalt pipe and cement mortar concrete. At the same time cement mortar is selected as the filling material and this can make the inside surface of steel pipe in alkali mediums. So the surface of steel pipe generates purifying films These films can prevent being rusted.
Data of cast basalt tilesChemical component
SiO2Al2O3Fe2O3TiO2CaOMgOK2ONa2OFeOP2O5MnO

42-45%	13-16%	13-14%	0.022	10-12%	10-11%	0.045	0.045	13-14%	<1%

Physical property
NO.ITEMPERFORMANCE VALVE

1	Specific gravity	2.9-3.05gm/cc
2	Compressive strength	3000-4500kg per sq cm(min)
3	Bending strength	300kg per sq cm(min)
4	Water Absorption	0
5	Solubility in Acids	0.006
6	Hardness	8(MIN.)Moh Scale
7	Modules of elasticity	11.1×104N/mm2
8	Expansion coefficient (room temperature to 60°C)	0.75×10-5/K
9	Thermal Conductivity	1.15W/mk
10	Special Heat Capacity	0.8kj/Kg.K
11	Highest Temperature For application	350°C

Advantages:
* Utilizing Cast Basalt enhances and improves operational life of plants.
* These are best suited for jobs where extensive cutting is needed.
* We can also deliver pre-cut tailored tiles based on the considerations of vibration, impact and other factors at client’s end.

---
