Silicone Rubber O-Ring/ Parts Making Machinery

Product Description

Silicone Rubber O-Ring/ Parts Making Machinery Product Parameters Technical Parameters:

Type	100T	150T	200T	250T	300T	400T	500T
Clamping force(Ton)	100	150	200	250	300	400	500
Stroke(mm)	250	250	280	300	300	300	300
Heating plate size(mm)	400*400 448*460	420*420 460*460	503*508 545*560	600*600 600*650	600*600 650*650	700*700 800*800	800*800 850*850
Diameter of cylinder(mm)	∅250	∅310	∅355	∅400	∅450	∅500	∅560
Horsepower(HP)	7.5*1	7.5*2	10*2	10*2	10*2	15*2	15*2
Type of mold opening	2RT/3RT/4RT UP-DOWN IN-OUT 2RT/3RT/4RT
Double shaft thermal electricity(kw)	14	22.5	27	34.5	36	46.5	48
Total power(kw)	19.5	33.5	42	49.5	51	68.5	70
Gross weight(kg)	6000	7500	8500	11000	13000	19500	24000
Machine size(cm)	270*230*227	300*230*235	320*260*250	360*295*265	365*295*270	385*315*300	410*320

All our presses can be customized according to your requirements in total pressure, platen size, daylight distance between plate, working layer and piston stroke.
Features 2-4. Configuration of Rubber Making Machine Press /Automatic Feeding Silicone Press Machine With Vacuum Cylinder 1. The machine adopts the advanced PLC control. The working program can be set in the cabinet and machine will work according to this program
2. Most spare parts for hydraulic system are imported from Taiwan
3. Machine body casting is made of FCD 50 ductile cast iron, which is processed by high tensile strength after aging passivation
4. The machine pillars/ columns are made of medium carbon steel, and its hardness can reach HRC55-58
5. The cartridge heater adopts three stages winding, nichrome wire, non-rusty
6. Oil seal are from Japanese NOK and Sakagmi Brand, it is wear-resisitant, durable and oil tight
7. Main electrical elements are from Schneider France, which can stabilize machine performance

Rubber vulcanizing press applies to all kinds of rubber ( Rubber Making Machine Press /Automatic Feeding Silicone Press Machine With Vacuum Cylinder ) vulcanizing and compression molding. Rubber vulcanizing press can be used to make O ring, sealing parts, oil seal, auto parts, rubber crash pad, rubber air spring, key board, medical rubber parts, rubber bottle stopper, silicone wrist band, water-stop tape, bridge support/bridge bearings, rubber cable, electronics insulators etc. Detailed Photos
Applicable products
Packaging & Shipping
About Dahua : Qingdao Dahua Machinery Co.,Ltd. which was established in 2000 is affiliated to Shandong Rubber Machinery Research Institute.We specialize in scientific research,production and sales of Rubber Machinery.As keeping extensive close cooperation with Qingdao University of science and technology,Shandong University,China University of petroleum,Chinese Academy of Sciences we have made a great contribution to the development of China Rubber Machinery.The company has experienced technical team,earnestly the grass-roots staff.We have advanced CNC machines and a variety of large and small mechanical processing equipment,heat treatment equipment and sophisticated detection equipment and introduced advanced UG 3D mechanical design software and performance optimization software in 2006. Our design team can design and manufacture non-standard rubber machinery according to customer requirements."Quality first, technology innovation" is the company's business principle,our products were rated as "excellent provincial famous brand" ,"free products" and exported to many countries and regions such as United States,Germany,France,Canada,Australia,South America and so on.With excellent quality and good customer service, the products have been well received among domestic and foreign customers!We sincerely welcome customers all over the world to visit our company or call us to have a business negotiation, hope to make a good faith and win-win cooperation with you and common development hand in hand. Customer SHOW:
HOT SALE
FAQ: Q: Are you manufacturer or trade company?
A: We are really 100% manufacturer.
Q: How many year's experience does your company have?
A: More than 20 years of concentration, we mastered several key technologies.
Q: What product can you supply?
A: Rubber press machine, Vacuum molding press machine, Injection Molding machine, Rubber mixer machine, calender machine, extruder machine and rubber product equipment solvtions.
Q: What are the operating modes of the machine?
A: With manual and semi-automatic operation mode.
Q: What control system does the machine use?
A: We use PLC as the core of control system, we ususlly usee Omron PLC.
Q: How long is the warranty of your machinery?
A: Our warranty is one year.
Q: How long is the delivery time?
A: Usually we need 40-60 days , if ther id inventory , we can finish the modification within one month, but it may take longer if ther are special requiements.

---
