Basic Info.
Application
Light Industry
Material
Monocrystalline Silicon
Specification
30w: 510*400*25(mm)
Packaging & Delivery
Package Size
110.00cm * 43.00cm * 3.50cm
Package Gross Weight
35.000kg
Product Description
Company Profile Yangzhou Huatai Lighting Group Co., Ltd. is a professional high-tech lighting enterprise integrating the design, R & D,
production, sales, project investment and engineering construction of a series of LED lighting lamps such as landscape
lighting, outdoor lighting, smart lighting, solar lighting, commercial lighting and hotel lighting. With advanced equipment,
the company devotes itself to the development of products, places itself at the root of street lamp mechanics, aesthetics and optics,
and is the enterprise mission and spirit of being a quality person! The production of the company mainly includes: road lighting series,
solar photovoltaic lighting series, high-power LED series, intelligent lighting series, transportation facilities series, building lighting series,
energy-saving controller series, wire and cable series and Waterscape fountain series, including nine categories and thousands of varieties.
Among them, road lighting series include: solar lamp, scenery complementary solar lamp, LED lamp High pole lamp, road lighting, combination lamp, landscape lamp, courtyard lamp, lawn lamp, projection lamp, traffic signal lamp, power pole, sign, gantry, energy-saving controller and supporting ballast, trigger, light control and time control switch box electrical products. The company's products have successfully passed the testing of internationalauthoritative testing agency SGS, and the products are exported to Sudan, the Philippines, Laos, Vietnam, Tanzania, the United Arab Emirates,Africa and other countries. "People-oriented, market-oriented, science and technology-based, industry as the standard and the world as the
goal" is our eternal pursuit. The people of Huatai lighting, who are open-minded, open-minded and ambitious, uphold the core values and
enterprise spirit of "abiding by morality, sincerity and goodness", and wholeheartedly welcome new and old customers for guidance and win-win
cooperation with professional team, high-quality service and firm confidence. The wise Huatai lighting people will not forget their original intention
and forge ahead, which will create our glory and usher in a better tomorrow!
Product Description Industry-specific attributes
| Cell size | 156.75mm × 156.75mm |
| Type | PERC,hbc |
| Panel Efficiency | High efficiency |
| Warranty | 25years |
Other attributes
| Place of Origin | Jiangsu,China |
| Panel Dimensions | 2385*1303*30/35mm |
| Model Number | HT-GF032 |
| Type | Perc, Hjt, Shingle, Black etc |
| Material | Monocrystalline Silicon |
| Application | Solar Power System |
| Frame | Silver/Black Anodized Aluminium Alloy |
| Front Glass | 3.20mm Tempered Glass |
| Warranty | 25 Years Output Power Guarantee |
| Weight | 3.5kg |
| Junction Box | IP68 Rated |
| Connector | Compatible Connector |
| Power | 10W-600W |
| Trademark | OEM/ODM |
Packing and delivery
| Selling Units: | Single item |
| Single package size: | 2400*1310*35 mm |
| Single gross weight: | 0.6kg |
Technical Specification of Solar Panel
| Peak Power(Wp)* | 610 | 615 | 620 | 625 | 630 |
| Maximum Power (V) | 45.60 | 45.70 | 45.80 | 45.93 | 46.03 |
| Maximum Power Current-Impp(A) | 13.38 | 13.46 | 13.54 | 13.61 | 13.69 |
| Open Circuit Voltage-Voc(V) | 55.25 | 55.40 | 55.55 | 55.70 | 55.85 |
| Short Circuit Current-Isc(A) | 14.11 | 14.18 | 14.25 | 14.32 | 14.39 |
| Module Efficiency (%) | 21.28 | 22.05 | 22.19 | 22.66 | 22.89 |
| Temperature Coefficient of Voc | -0.25%/ºC |
| Temperature Coefficient of Isc | 0.045%/ºC |
>>
