Automatic Three Spindle Carving Wire Brush Woodworking Relief Drawing Machinery

Product Description

We supply high quailty Relief Drawing Machine Product show
Product Parameters

Model	LZLS600	LZLS1300
Max. working width	600mm	1270mm
Max working thickness	5-90mm	4-80mm
Feeding speed	5-30m/min	5-30m/min
First unit power	7.5kw	11kw Wire brush roller
Second unit power	1.1kw*3	2.2kw*4pcs Brush disc
Third unit power	5.5kw	7.5kw Wire brush roller
Fourth unit power	4kw	7.5kw Nylon polish roller
Fifth unit power	4kw	5.5kw Nylon polish roller
Feeding power	2.2kw	4kw
Lifting power	0.37kw	0.37kw
Oscillating power	60w*5	90w
Total power	27.17kw	42.55kw
Overall dimension(L*W*H)	3500x1650x1750mm	3500x2200x1800mm
Weight	2300kg	4000kg

Function
1 This machine is special designed for the flat products which need surface relief drawing result like archaize floor, furniture, table-board, handicraft etc and it's a new generation products processed by this machine, the flat surface is skid free, stereoscopic and beautiful
2 Conveyor belt, drawing rollers and polishing rollers all use independent controlled imported motors and the feeding use frequency conversion, which make the surface effect better and more precision controlled.
3. Drawing rollers, polishing rollers can be easily removed or remounted with precise positioning The height is read by the meters, easy to operate
4 Each unit has oscillating device, which make the work pieces more clear Each unit of roller or brush discs can be lifted independently
5 Different quantities vertical brush discs, Wire drawing rollers and polishing rollers can be equipped at different types of machines based on different materials
Product Details

Samples
Company Profile
Qingdao Haozhonghao Woodworking Machinery Co., Ltd. previously was Qingdao Woodworking Machinery Manufacturing Company, and was established in 1958.
With more than 50 year experience in making woodworking machines, our main products are Sanding Machine, Panel Saw, Guillotine, Veneer Slicer and Grinder. We firstly put BB1342 vertical slicer into the market in China. We developed BB1135B Horizontal Veneer slicer by integrating the internal and international technologies, the max slicing width reaches 1300mm. We are the first company which was certified by ISO9001 in the industry, and also a hi-tech enterprise in Qingdao.
We have more than ten years experiences in exporting high quality woodworking machinery, especially Sanding Machine, Veneer Slicer and Grinder.
Our website is sanding machine.en.made-in-china.com; you could get more information about our company and our products.

---
