Plastic Chair Making Injection Molding Machine with PP PE Material

Product Description

Automatic Computerized Sinotech Standard Export Wooden Box Plastic Chair Injection Molding Machine
Product Description
SINO-TECH ST-1000S injection molding machine is designed for plastic dustbin, chairs, car bump pallet etc. It is with demoulding linkage which shorten the plastic parts cycle time. ST-1000S with high speed, stable performance and it is energy-saving. Our customers can get higher production with same labor and cost.
Main Features1. 30% higher energy saving than using traditional variable pump.
2. Stable and smooth movement supported by AC servo motor.
3.Effective reduction of energy consumption due to reduced oil.and cooling water attained by hydraulic system.
4. High performance European B&R control system.
We are professional plastic injection molding machine manufacturer for all kinds of plastic products, Clamping force from 50 to 4000Ton, injection weight from 50 to 10000g. Also we have CE and ISO certification.
Product Parameters

Injection Unit			ST-1000S
SCREW DIAMETER	mm	120
SCREW L/D RATIO	L/D	20.2
THEORETICAL SHOT VOLUME	cm3	5880
SHOT WEIGHT(PS)	g	5350
INJECTION PRESSURE	kg/cm2	1430
THEORETICAL INJECTION RATE(PS)	g/s	1001
PLASTICISING CAPACITY	g/s	130
SCREW STROKE	mm	520
SCREW TORQUE	N.m	869
HEATING POWER	Kw	68
HEATING NUMBER	qty	6
MAX.SCREW ROTATE SPEED	r/min	10-160
Clamping Unit
MAX.CLAMPING FORCE	Ton	1000
MAX.OPENING STROKE	mm	1160
MOULD HEIGHT	mm	450-1200
DISTANCE BETWEEN MOULD PLATENS	mm	2360
SPACE BETWEEN TIE BARS(V×H)	mm	1110×1110
MOULD PLATEN SIZE(W×H)	mm	1670×1670
EJECTOR FORCE	KN	24.5
EJECTOR STROKE	mm	350
EJECTOR QUANTITY	/	1 or 21
Other
PUMP MOTOR POWER	KW	90
PUMP Q. MAX	L/min	540
SIZE	m	12.5×3.5×3.1
NET WEIGHT	Ton	61

Seller Recommendation

Detailed Photos

Application

Company Profile

FAQ
1. who are we?We are based in Jiangsu, China, start from 2011,sell to North America(30.00%),South America(20.00%),Western Europe(16.00%),Oceania(10.00%),Mid East(10.00%),Eastern Europe(5.00%),Southeast Asia(5.00%),Africa(4.00%). There are total about 5-10 people in our office.2. how can we guarantee quality?Always a pre-production sample before mass production;Always final Inspection before shipment;3.what can you buy from us?Extrusion Blow Molding Machine,Pet Blow Molding Machine,IBC Cage Production Line,Plastic Extrusion Line,Waste Plastic Recycling And Pelletizing Line4. why should you buy from us not from other suppliers?Our company have the strict system from the material purchase,machine part processing and inspect. We have the detailed Assemble prcess according to the machine Assemble structure. We test not one time before the machine delivery to the customer factory.5. what services can we provide?Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery;Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian

---
