Electric Paint Mixer

US$3,500.00 1 Piece (MOQ)

Basic Info.

Model NO.

ESR

Certification

CE, ISO

Condition

New

Stirring Type

Forced

Working

High Speed Mixer

Model

Ebf-5--- Ebf-55

Usage

Industrial

Product Type

Paint

Mixer Type

Homogenizer

Layout Type

Verticle

Mixing Drum Shape

Drum

Operating type

Continuous Operating

Transport Package

Wooden Case

Specification

CE, SGS

Trademark

ELE

Origin

Shanghai, China

HS Code

8479820090

Production Capacity

500PCS Per Year

Product Description

homogeneous homogenized machinery/electric paint mixer
Descriptions: The EBF Paint Mixer ( high speed mixer / disperser / dissolver ) is suitable for batch production, it is apply to all kind of liquid to pre-mix, disperse, color matching, etc.
Features:
1. Hydraulic lifting the frame can turn around flexible
2. Can match with cover incase of material splashing or flying and volatilization of solvent based product during working.
3. Less air absorption during working
4. Paint Mixing Machine can blend and dissolve product quickly
5. With inverter, various speed control, low noise and long-time continuous production
6. Stable performance, high efficiency
7. Paint Mixing Machine with clamp or belt is optional
8. Motor can be explosion-proof, and the dispersing tank can be vacuum or seal
9. Paint Mixing Machine can be hydraulic lift or pneumatic lift
10. Type: Floor type and platform type
11. One machine can serve several tanks

Model	Main Power(kw)	Speed(rpm)	Diameter of disc(mm)	Stroke(mm )	Pump Power(kw )	Length (mm)	Height(mm )	Centre Distance(mm)
EBF-4	4	1400	100`200	700	0.75	1400	1420	580
EBF-7.5	7.5	1400	200`300	900	1.1	1650	1850	765
EBF-11	11	1400	200`300	900	1.1	1650	1850	765
EBF-15	15	1400	200`300	900	1.1	1800	1850	915
EBF-18.5	18.5	1250	300`400	1200	2.2	1800	2120	1100
EBF-22	22	1250	300`400	1200	2.2	2360	2120	1250
EBF-37	37	1250	300`400	1200	2.2	2520	2120	1400
EBF-45	45	1250	400`500	1500	2.2	2830	2750	1400
EBF-55	55	1250	400`500	1500	2.2	2830	2750	1500
