Product Description

PCD Hub drilling bit
Product Description
PCD Drills Are Carbide Bodies Tipped With PCD Cutting Edges For A Variety Of Aluminums And Other Non-Ferrous Materials.
PCD Cutting Tools, Fine Boring Tools, And Inserts Can Be Produced With A New Chipbreaker Technology, Extremely Productive And Tailored To Satisfy Your High-Volume Production Needs. A Chipbreaker Design Range And The Correct PCD Grade Choice Are Available To Provide The Highest Tool Life And Cutting Data As Well As Unmatched Surface And Diameter Tolerance Quality. The Reaming Technology Based With Adjustable Blades Enables You To Achieve Highest Accuracy And Surface Quality And Four Cutting Edges With PCD, CBN, Carbide, Or Cermet. The PREZISS System Provides You With The Most Stable Pocket Seat And Fail-Safe Clamping, From Smallest To Largest Diameters. PCD Tipped, Steel Or Solid Carbide Body Adding Chipbreaker Control, Allows You To Improve Chip Evacuation Increasing The Productivity As Well As A Higher Tool Life
Advantages
Increases Tool Life And Reduces Cycle Times
Can Run At Higher Penetration Rates
Produces High Quality Consistent Reamer Like Holes
PCD Grades Available By Application
Features
Has Self Centering Point
Internal Coolant Or Non-Coolant Option
Superior Ground And Polished Surface Finish
Detailed Photos
Product Parameters
Specification

Name	Size	S(mm)	d(mm)	h(mm)	D(mm)	1 (mm)	L (mm)
JLT0410	4*1*2	4	4	1	2	6.4	50
JLT0605	6*0.5*3	6	6	0.5	3	9.6	50
JLT0610	6*1*3	6	6	1	3	9.6	50
JLT0620	6*2*3	6	6	2	3	9.6	50
JLT0810	8*1*4	8	8	2	4	12.8	50
JLT0815	8*1.5*4	8	8	1.5	4	12.8	50
JLT0820	8*2*4	8	2	2	4	12.8	50
JLT0830	8*3*4	8	8	3	4	12.8	50
JLT1010	10*1*5	10	10	1	5	16	60
JLT1015	10*1.5*5	10	10	1.5	5	16	60
JLT1020	10*2*5	10	10	2	6	16	60
JLT1030	10*3*5	10	10	3	5	16	60
JLT1050	10*5*5	10	10	5	5	16	60
JLT1210	12*1*6	12	12	1	6	19.2	60
JLT1220	12*2*6	12	12	2	6	19.2	60
JLT1230	12*3*6	12	12	3	6	19.2	60
JLT1250	12*5*6	12	12	5	6	19.2	60
JLT1420	14*2*7	14	14	2	7	22.4	75
JLT1450	14*5*7	14	14	5	7	22.4	75
JLT1620	16*2*8	16	16	2	8	25.6	75
JLT1650	16*5*8	16	16	5	8	25.6	75
JLT1680	16*8*8	16	16	8	8	25.6	75

Our Advantages

Packaging & Shipping

FAQ
1) When can I get the price?
We usually quote within 12 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.

2) How long can I expect to get the sample?
After you pay the sample charge and send us confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3-5 workdays. You can use your own express account or prepay us if you do not have an account.

3) Are you a trading company or manufacturer?
We are a professional manufacturer. We not only own our tools factory but also have cemented carbide factory.

4) How long can I expect to get the sample?
After you pay the sample charge and send us confirmed files, the samples will be ready for delivery in 7-15 days. The samples will be sent to you via express and arrive in 3-5 workdays. You can use your own express account or prepay us if you do not have an account.

5) How about your stock?
We have large quantity products in stock, regular types and sizes are all in stock.

6) Is free shipping possible?
We don't offer a free shipping service. We can have a discount if you buy a large number of products.

---
