| US$499.00-560.00 | 1 Piece (MOQ) |
| Size | 162X76.8 X 13.9mm |
| Weight | 252g(including battery) |
| Display | 5.72inch 18:9 HD+(1440*720) |
| Touch panel | Gorillaglass, plated with anti-fingerprint film, supports wet hand operation |
| Backlight | LED Backlit |
| POWER | 4600mAh , 3.8V removable lithium battery; spare battery(optional): 150mAh More than 8hours working time, and standby time 300hours |
| SIM | SIM+TF: nanosim+nanosim/TFCard |
| USB port | Type-c, Support OTG |
| Network connections | 4G/3G/2GsWi-FisGPRS |
| Notification | CueTone; multi-color led; Vibration |
| Keyboard | 3 virtual buttons: Backs Home,Menu |
| Audio frequency | A microphone, speaker, receiver |
| Operating temperature | -20ºC to 55ºC |
| Humidity | 5% to 95% (Non-condensation) |
| Drop specification | Within the working temperature range, it can withstand repeated falls from a height of 1.5 meters to the concrete floor |
| Roll Specification | Can Withstand 200 times 1.6 ft/0.5 m rolling impact; meets or exceeds IEC |
| Vibration | Random(10 Hz-30KHz);60 minutes per shaft |
| Electrostatic protection | +/- 10kv air discharge +/-6kv contact discharge |
| Protection level | IP67 |
| WWAN | Asia + Europeband: GSM:Band2/3/5/8 WCDMA:Band 1/2/5/8 TD-SCDMA: Band 34/39 CDMA:Band BCO TDD-LTE:Band 34/38/39/40/41 FDD-LTE: Band 1/3/5/7/8/20 American band: GSM:Band2/3/5/8 WCDMA:Band 1/2/4/5 CDMA:Band BCO TDD-LTE:Band 40/41 FDD-LTE:Band B1/2/4/5/7/28A/28B |
| WIFI | Wifi Frequency:2.4GHz&5GHz Protocol:802.11 a/b/g/n/ac/r/e/i Fast Roaming |
| navigation | Beidoux Glonass,GPS,GalileOxQZSS |
| Version | Bluetooth 5.0 |
| 1.No reaction when putting the NFC card close to the device. | Step 1: Please make sure that the card-reading function is opened; Step 2: Check whether the frequency of the card matches well with the protocol; ( Currently, it only supports high-frequency card including MF0,MF1,15693,CPU). |
| 2.The requirement of RFID products with UHF to environment. | Metal and liquid (water) material have a strong interference to the UHF signals ( the closer to the tag antenna, the stronger interference of the signal); It is able to adopt anti-metal tag in the metal environment, however, it still remains hard to solve problems in liquid environment. |
| 3.There is light emitting from the scanning head but fail to scan. | If it fails to scan suddenly in use, the same setting of the scanning head and the barcode to be scanned may possibly result in it. If you change the setting of the scanning head unintentionally, you are supposed to scan other types of barcodes and send the result feedback to Cilico. |
| 4.The left and right scanning button fail to work or only one side button could work | Step 1: Please make sure that the left and right scanning options are opened; Step 2: Close the scanning type APP; Step 3: Try to scan with system scanning option; if it works, then the device is working properly. |
| 5.What am I supposed to do when the reflash process is interrupted? | Step 1: Disconnect USB; Step 2: Take out the battery and install the battery agian; Step 3: Repeat reflash process. |
| 6.The device fails to charge. | Step 1: Change the battery or charge with the USB cable and try to start up; Step2: If it still fails to charge to start up after changing the battery, it is possible that the battery is over discharged. Please keep the charging connection with USB cable, then take out the battery and instsall again, activating the battery by repeating 3-4 times. Try to start up after charging for 30 minutes. |
| 7.Why does the device enter factory mode when it is turned on. | The possible cause is that the volume - key is pressed when the phone is started up. You can press the Volume - key or select Restart and press the power button to restart the phone. |
| 8.What is the best distance for bar code scanning | The optimal scanning distance depends on the size of the bar code. The optimal scanning distance of the large bar code will become longer, while the optimal scanning distance of the small bar code will become smaller. Generally, the optimal scanning distance is between 10-15cm. |
| 9.How do I access the Developer options | In Settings/About Phone, click on the Build number 5 times to exit About Phone and Click on system-Advanced in order to see the developer options. |
| 10.The kind of protocol used by UHF | International standard 18000-6C protocol used |
| 11.How do I view the device version | Enter from device, click Settings - About Phone - Build number |
| 12.How do I restore the device to factory Settings | Device interface click Settings - System - Reset Options - Erase all data(factory reset) |
| 13.Why can't the device recognize the phone card and access the Internet by phone | Step 1:Ensure that the mobile phone card is installed in the SIM card slot Step 2:Ensure that the data traffic switch Settings - Traffic Usage - Carrier-data switch are enabled |
| CPU | Octa-core 2.0GHz |
| OS | Android 11 |
| Memory | Standard 4GB+64GB (LPDDR4X+EMMC), Option 3GB+32GB/6G+128G |
