Automatic Yanpeng 15*8.6*10 Nonwoven PP Spunbond Face Mask with CE Yp-M, mm

Product Description

Automatic YANPENG 15*8.6*10 Nonwoven PP Spunbond Face Mask with CE YP-M, MM Product Description
We enable our customers worldwide to produce nonwoven fabrics economically, reliably and sustainably.
Our mainly products are:spunbond nonwoven lines such as single beam, double-beam and three-beam PP lines PET lines Bico(PE/PP)and spunmelt (spunbond & meltblown) lines such as SMS, SSMS, SMMS, SSMMS.
The max speed of the last updated SSMMS spunmelt line has reached up to 600m/min, the grammage will be from 8-80gsm with high technical performance.Process flow: Feeding→Extrusion Melting→filtering→metering→spinning→Cooling→Stretching→Web spreading→Thermal bonding→slitting→collecting

Model No.	YP-S-1.6	YP-S-2.4	YP-S-3.2
S(Product width)	1600mm	2400mm	3200mm
Equipment size	15*8.6*9.5m	15*9*9.5m	15*10*9.5m
Speed	150m/min	150m/min	150m/min
Gram Weight	10-180g/m2	10-180g/m2	10-180g/m2
Yield(Products according to70g/m2)	4T/Days	7-8T/Days	9-10T/ Days

Production Application
Polypylene (PP) Spunbonded Nonwoven Fabric Application
This polypropylene(PP )spunbonded nonwoven fabric production line has advantages of superior performance, beautiful color, and good quality. It can form a fibre web symmetrically and is complete in types. It can also add recycled material and stuffing to reduce the cost of products.
01 Household Items
Suit Cover Knitwear Cover. Garderobe Cover. T able Cloth. Other Products Include Pillow Slip, Bedspread, Car Cover Cover For Quilt, Computer, Air Conditioner And Fan Cover Etc
02 Medical And Hygiene Article
Operation clothes,exposure suit,disinfect cloth respirator,diaper,duster cloth,wiping cloth,wet face cloth,flexible towel roll,hairdressing products,sanitary towel, pad and any cloth for single use.
03 Commodity and labor production products
Cloth sleeves,apron,sauna cloth etc. Common purpose bags like shopping bag,gift bag,advertising bag,suit bag,quilt storage bag,samples handbag,ads bag,garbage bag etc.
04 Garments And Shoes
Clad And Linning , Shoes Lapping Cloth,
Shoes Bag,Shoes Cover Etc.
05 Industrial and Agricultural Usage
Roadbed Cloth, Dykes And Dams Cloth,
Waterproof Rolling Fabric,Covering Cloth,
Car Interior Decoration Cloth, Filtering Material,
Oil Absorption Material Etc.
Detailed Photos
Hopper system
The main feeding hopper capacity: Max 500kg/hr: Contains vacuum pump, hopper, suction gun as well as suction pipeline; Uses the programmable touch screen control to attract the material; use the stainless steel to make the suction pipeline( pipeline + high strength hose); 7.5kw vacuum pump;
Three master-batch feeding hopper: Master-batch hopper one: proportion 0.5---5%, precision: +/--2%; Master-batch hopper two: proportion 5---10%, precision: +/--2%; Master-batch hopper three: Optional spare Webformer Used to supply carrier for the drawn fiber webs, including a drive system for web forming belt, a suction channel device, a sealing device, an automatic correcting device, belt tensioning device, a frame and a prepressing roller, oil furnace and web support roll.Up drawing system and Down drawing system
a. made of section and δ=3mm mirror stainless plate
b. the inner clearance is adjustable
Spinning box: Uses the heat conduction oil to heat. Heating: 48KW, the maximum heating temperature is 250 degrees; Uses 300cc the metering pumps, each metering pumps actuate by the synchronous motor. Max speed: 40RPM, Motor: 5.5KW. The manifolder and the melt pipeline have the high quality thermal insulation material, the outside lap use the stainless steel plate, the exterior temperature are not higher than 60 degrees. Spinning module 1 set Each set of modules include: Aluminum nature gasket; Distribution board; View more products,please click here...
