China Good Price Centerless Grinding Machine Cylindrical Grinder for Bearing Rings, Cylinder

Product Description

Product Description
Casting, natural aging and artificial heat treatment for reasonable deformation and better durability.
1.2 GW and RW(Regulating wheel)
400mm width for larger grinding amount and higher efficiency.
Double feeding movement, work-rest fixed onto the machine body, easy for auto loading and unloading adjustment.


1.3 Feeding
Plastic-surface guideway for motion sensitivity, micron feed, vibration resistance, and antifraying.
Manually by hand wheel for feeding, min feeding amount is 0.01mm.
1.4 Dressing for GW and RW GW dresser and RW dresser: Hydraulic transmission for reciprocating,step-less speed adjusting, manual dial for RW dresser feeding.


1.5.Cooling
Cooling tank with magnetic coolant separator

1.6.Technical Data:

1. Plunge-feed
(1) Grinding diameter	10~200mm
(2) Grinding length	390mm
2. Through-feed
(1)Grinding diameter	10~200mm
(2)Grinding length(standard work rest)	300mm
3. Grinding Wheel Spec.	P600×400×305mm
4. Regulating Wheel Spec.	P350×400×203mm
5. Grinding Wheel Speed	1114r/min
6. Regulating Wheel Speed(Stepless)
(1) Working Time	12~80r/min
(2) Dressing Time	80~200r/min
7. Transverse displacement of regulating wheel frame	-15~+15mm
8. Swiveling Angle of Regulating Wheel
(1) Vertical	-2°~+4°
(2) Horizontal	-2°~+4°
9. GW Frame Min. Feed Amount	0.001mm
10. RW Frame Feed Amount
(1) Handwheel feed per revolution	1mm
(2) Handwheel feed per cell	0.01mm
11. GW Dresser Feed Amount	0.01mm
12. RW Dresser Feed Amount	0.01mm
13. Swiveling Angle of RW	-2°~+4°
14. Height from center line of GW & RW to work rest	290mm
15. Motor power
(1) GW motor	30KW
(2) RW motor	3KW
(3) Water pump motor	0.25KW
(4)Lubrication pump motor	0.12KW/pcs
(5) Hydraulic pump motor	0.75KW
(6) Magnetic motor	0.04KW
16. Power supply	3N 50HZ 380V
17.Machine dimension(L*W*H)	3600×1850×1720mm
18.Machine weight	about 9000Kg

1.7.Main Accessories:

Name	SPEC.	QTY	Unit	Brand
Converter for RW	3.7KW	1	pc	Mitsubishi
RW motor	2.2KW	1	pc	Wannan
GW motor	30KW	1	pc	Wannan
low-voltage apparatus		1	set	Schneider

Grinding Examples&Operations
Automatic Solution
Company Profile
Jiangsu Phisong CNC machine Co., Ltd., known for it′s professional centerless grinding technology at home and abroad, Phisong CNC inherits and absorbs the essence of the advantages on cylindrical grinding machine, centerless grinding machine design, production and manufacturing industry. Our products are selected by a number of famous Top-500 enterprises and listed companies at home and abroad and exported to countries and regions in Europe & America, Russia, southeastern Asia etc.We presently built offices with modernized environment, process with advanced producing technology, Adopt ISO9001 international quality management system. For different processing requirements, we customized professional processing technology for customers in improving their processing level and production efficiency with concept of professional skill, integrity and enthusiasm.Phisong gathered a large number of professional elites, based on the full range of product quality management, and the employment of senior experts as a long term production technology consultant, with a professional attitude, devoted to product R&D and production. We have a wide range of applications: From micro nozzle needle to high precision pump piston to heavy rail shaft, we continue to develop centerless grinding technology, won the majority of customers′ praise.
FAQ
Certifications
Packaging & Shipping
Company Exhibition&Visiting

---
