Automatic Label/Tags/Hangtags/Cosmetic/Medicine Box/Paper Cup Die Cutting Creasing Machine

Product Description

Introduction.
The die cutting and creasing machine is an equipment especially designed for die cutting the ordinary cardboard, corrugated board, plastic and leather products. It is widely used in the printing, packing decorating and plastic industries. The machine has features such as compact structure, fine workmanship, big pressure, high precision and easy and reliable operation etc.
Feature:
1. High strength due to one piece casting by using top quality materials for the machine body.
2. Smooth running, big pressure and low noise are obviously remarked as herringbone gear input and helical gear output mechanism is adopted.
3. Single plate electromagnetic clutch is sensitive and reliable.
4. Operational altitude is reasonably arranged, moveable platen opens to its optimum.
5. The electrical system is designed with IEC standard.
6. With functions as single, continuous operation and opening well, and the dwell time is adjustable.
7. The safely system is reliable.
8. With concentrated lubricating system.
Main Specifications.

ModeI	Inner Chase size	Speed	Max.pule length	Motor Power	Weight	Overall Dimensions
ML-750	750x520mm	25±2(sprokes/min)	<14m	2.2kw	1800kg	1360x1400x1300mm
ML-930	930x670mm	23±2(sprokes/min)	<25m	4kw	3000kg	1680x1680x1640mm
ML-1040	1040x720mm	23±2(sprokes/min)	<30m	4kw	4000kg	1850x1780x1700mm
ML-1100	1100x800mm	20±2(sprokes/min)	<26.5m	4kw	4500kg	1900x1780x1700mm
ML-1200	1200X820mm	20±2(sprokes/min)	<26.5m	4kw	4500kg	1900x1900x1750mm
ML-1300	1300x920mm	18±2(sprokes/min)	<38m	5.5kw	5600kg	1920x2140x1800mm
ML-1400	1400x1000mm	17±2(sprokes/min)	<38m	5.5kw	6200kg	2010x2400x1930mm
ML-1500	1500x1050mm	17±2(sprokes/min)	<40m	7.5kw	6800kg	20100x2480x1960mm
ML-1600	1600x1250mm	13±2sprokes/min	<50m	11kw	11000kg	2500×2200×2000mm
ML-1800	1800×1250mm	13±2sprokes/min	<60m	11.5kw	13500kg	2510×2300×2000m
ML2000	2000×1400mm	13±2strokes/min	<60m	15kw	16000kg	2270×3100×2150mm
ML2500	2500×1500mm	13±2strokes/min	<75m	18.5kw	20000kg	2300×3600×2150mm

Qianding Machines Loaded Into Container At the Ningbo Port.

---
