| Model | ES500-MV-N86L/E |
| Signal System | NTSC | PAL |
| Scanning System | 2: 1 Interlace |
| Scanning Frequency(H) | 15.734 KHz | 15.625kHz |
| Scanning Frequency(V) | 59.94 Hz | 50Hz |
| Image Sensor | 1/3 inch Super HAD CCD |
| Sync. System | Internal |
| Total Pixels Number | 811(H) x 508(V) 410K | 795(H) x 596(V) 470K |
| Effective Pixels Number | 768(H) x 494(V) 380K | 752(H) x 582(V) 440K |
| Horizontal Resolution | 600 TV Lines (BW 650TV Lines) |
| Video Output Level | 1.0 Vp-p (75Ω , Composite) |
| S/N Ratio | More than 50dB (AGC Off) |
| Lens Mount | CS Mount |
| Min. Illumination | 0.1 Lux (Color), 0.001 Lux (B/W) |
| Day & Night | YES |
| Digital Noise Reduction (SDNR) | Low, Middle, High, Off |
| White Balance | ATW, Manual, Push |
| AGC | On/Off |
| SBLC | Off, Low, Middle, High |
| Flickerless | On/Off |
| OSD Menu | English, Chinese |
| Mirror Function | Horizontal |
| Privacy Zone | On/Off (4 Programmable Zone) |
| Motion detection | On/Off (4 Programmable Zone) |
| Electronic Shutter Speed | 1/60~1/120, 000 | 1/50~1/120, 000 |
