Automatic High Efficient Continuous Carbonizing Furnace for Agricutural Waste

Product Description

Automatic High Efficient Continuous Carbonizing Furnace for Agricutural Waste
As a professional charcoal machines manufacturer in China, our company always adhere to the principle of quality first.
Product Application of Continuous Carbonizing Furnace
The smokeless sawdust continuous carbonization furnace is mainly used for relative puffy coking of biomass material, the device is still using the char gasification type principle, with the advanced smoke-free environment carbonization process: the whole equipment by the gasification system (gasifier, spray tower, filter), purification system (spray tower, oil-water separator, filter), carbonized system (carbonized host, screw feeder, screw blanking) machine, cooling machine, conveyor, control system (control cabinet), the whole coking process for automation production, automation.
Continuous carbonizing furnace can carbonized the woodiness material containing carbon (below 15 mm granular size)such as: sawdust, rice husk, peanut shell, plant straw, bamboo, coconut, bark, palm shell, wood chips, date, olive waste, nut shell etc wood containing carbon materials.
Main Features of the continuous carbonizing furnace
*Simple structure in linear type, easy in installation and maintains.
*Adopting advanced world famous brand components in pneumatic parts, electric parts and operation parts.
*High pressure double crank to control the die opening and closing.
*Running in a high automatic and intellectualization, no pollution
*Apply a linker to connect with the air conveyor, which can directly inline with filling machine .
*Large volume, high carbonization rate, strong production capacity.
*Cooling time is short, environmental protection.
Main parameters of the Continuous Carbonizing furnace

Model	Capacity(t/h)	Power(kw)	Diameter and Length of the Main Furnace(mm)	Dimension of cooler(mm)	Dimension of the complete set(m)
YLXT-1000	0.5-0.8	21	φ1020*9200	φ1200*2900	9.2*1.45*1
TLXT-1200	1	30	φ1200*11200	Φ1500*2900	11.2*1.65*1

Raw Material and Final Product:
Raw material: sawdust, rice husk, small wood sticks, coconut shell, palm kernel shell, peanut hulls, corn stalks, bagasse, twigs, rice husks, bamboo shavings, sorghum stalks, sunflower husks, distilled grains, corn cobs, coconut husks, coffee grounds, cotton stalks, bean stalks, dry leaves and other biomass materials, agricultural wastes.
Input raw material size need less than 15cm
Rate of raw material and final products:
According to the humidity and the density.
For low density material,suck as rice husk, sawdust, we can get 1 ton charcoal from about 3-3.5 tons raw material ,for high density raw material such as bamboo shavings, coconuts shell, palm kernel shell, We can get 1ton charcoal from about 2.5-2.7 tons material.
After carbonizing, we can make briquettes:
Briquette roller pressing production line flow as following
Crushing process-----Mixing process------Briquette making process----Packing Process
Other Biomass Processing machinery
Packing and shipping
1. Nude and loaded in the container.
2. We will provide the machine as quickly as possible after the customer playing the order, also with high capacity. we will track the shipping for customer whenever they need.
Our Services
1. We will give detailed introduction of the automatic high efficient continuous carbonizing furnace according to the client capacity requirement.
2. Share any information about the Automatic high efficient Continuous Carbonizing Furnace that the clients need, like detaield pictures, video,etc
3. Design full briquette making line for client.
4. Give detailed instruction manual and video to the customers.
