Specification
| SP1840
|
X-axis travel
| 4200mm
|
Y-axis travel
| 1850mm
|
Z-axis travel
| 1000mm
|
Distance from spindle nose to worktable surface
| 250-1250mm
|
Worktable size(WxL)
| 4000×1500mm
|
T-slots size (NxWxD)
| 9-22-160mm
|
Max. load bearing of worktable
| 12000kgs
|
X/Y/Z guideway size
| Roller 2-55/2-55mm,Z-axis hard guideway
|
Rapid feed speed of X axis
| 10000 mm/min
|
Rapid feed speed of Y axis
| 10000 mm/min
|
Rapid feed speed of Z axis
| 10000 mm/min
|
Main motor power
| 18.5/22KW
|
Spindle model
| BT50/Φ190
|
Motor torque
| 117.7N.M
|
Spindle taper
| BT50
|
Blind rivets aize
| P50T-2-MAS403
|
Driven type
| Gear box 1:4
|
X/Y/Z linear guideway size
| X/Y-axis 2-55# roller linear guideways
|
X/Y/Z ball screw size
| X-axis 8020,Y-axis 6320,Z-axis 5016
|
Tool magazine capacity
| 24pcs, 32pcs
|
Tool arbor
| BT50
|
Max. tool dimension
| Φ110/Φ220mm
|
Max. length of tool
| 300mm
|
Max.tool weight
| 18kgs
|
Positioning accuracy
| 0.03mm
|
Re-positioning accuracy
| 0.018mm
|
Machine weight
| 28000kgs
|
Overall size (LxWxH)
| 10800×6000×5500 mm
|
