| PoE Camera | |
| Image Sensor | CMOS |
| Effective Pixels | 8MP |
| Day/Night | Auto(ICR) |
| IR Range | Up to 30 m |
| Focal Length | 2.8/3.6 mm |
| White Balance | Auto |
| Noise Reduction | 2D/3D DNR |
| Region of Interest | Support |
| Motion Detection | Support |
| Privacy Masking | Support |
| Ethernet | 1 Ethernet (10/100 Base-T) RJ-45 Connector |
| Reset | Support |
| Power Supply | DC12V/POE (IEEE 802.3af) |
| Working Environment | -20°C ~ 50°C (-4°F ~ 122°F ) |
| NVR | |
| IP Camera Input | 8 Channel |
| HD Output | 8MP,5MP,4MP,3MP,1920×1080, 1440×900, 1280×1024 |
| VGA Output | 1920×1080, 1440×900, 1280×1024 |
| Decoding Capacity | 8CH 8MP |
| Recoding Resolution | 8MP,5MP, 4MP, 3MP, 1080P, 720P, D1 etc. |
| Recording Mode | Manual, Schedule (Regular, Continuous), Event |
| Trigger Events | Motion Detection, Video Loss, Alarm in |
| Sync Playback | 8/1 |
| Search Mode | Time /Date, Alarm, Picture grid, Event |
| Backup Mode | USB Device, Network |
| Interface | 1 RJ-45 port (100/1000Mbps) |
| PoE | 8 Ports (IEEE 802.3af), 32W |
| HDD | 1 SATA Ports, up to 8TB for each HDD |
| Audio I/O | 1/1 |
| USB | 2 ports (USB 2.0 × 2) |
| Power Supply | DC52V/2.3A |
