Automatic Vertical Electric Gas Welder/Egw/ Automatic Tank Welding Machine/ Tank Welding Tractor/ Tank Welding Carraige/ Tank Vertical Seam Welder/ Tank Welding

Product Description

AUTOMATIC TANK VERTICAL UP WELDING MACHINEI.Product description
For the tank welding machine, we has been sold more than 20 countries in more than 1000 projects sites.We have confidence for the machine quality and after sale service. We can provide single side, double side crude oil, LNG tank, fuel tank, water tank horizontal seam, vertical seam and bottom plate/corner welding machine.In Middle East, we have sold to UAE, Saudi Arabia, Oman, Bahrain, Kuwait. In Africa, we have sold machine to Cameron, Sudan, Egypt, Senegal, Nigeria,Zambia,Ethiopia,Senegal,etc. We have sold to vietnam, Indonesia , Malysia,Philippines,Singapore, Mexco,Mogulia, Russia,etc
I.Specification

Parameters	Data	Welder type	Suitable for tanks
Min Diameter	4.5m	Single Sided Girth Welder	top to bottom and bottom to top way, two function way
Plate Width	1.4-3.2m	Double Sided Girth Welder	can be splited into two girth seam weder, can work with jacks after split
Plate Thickness	8-45mm	Girth Welder for LNG/LPG Tank	top to bottom and bottom to top way, two function way
Construction Method	Top to Bottom&Bottom to Top	Girth and vertical seam MIG/MAG welder	top to bottom and bottom to top way, two function way
Welding Speed	300-500mm/min	Vertical EGW (electric gas welding)	top to bottom and bottom to top way, two function way
Fast Speed	2650mm/min	Butt&corner welder	bottom plate and corner seam

II,Prameter
Vertical seam welding machine

Welding Process	:	Electrogas welding
Model	:	WEGW-I
Plate Thickness	:	8 - 45mm
Plate Material	:	Carbon steel
Groove	:	Single V groove Double V groove
Seam Position	:	Vertical Weld /3 G welding
Min Tank Diameter	:	Φ6.0m
Plate Width	:	1.6 - 3.0m (Can be customized )
Power Input	:	380V/3PH/50HZ (Can be customized )
Erection Method	:	Bottom To Top and bottom to top
Dimension(L x W x H)	:	4000mm x 1900mm x 1100mm
Gross Weight	:	1200kg

Butt & corner welding machine
III.ModelIV.Photo
New type Machines for UAE client
Vertical seam welding machine in Senegal
Client visit China project site
vertical seam welding machine in Egypt
Vertical seam welding machine in Singapore
IV.Company Introduction
Wincoo Engineering Co., Ltd (WINCOO) is engaged in bringing the most suitable solutions/equipments for client, fabricators, EPC/C companies on pipe fabrication, tank construction, pipeline construction,industrial production lines, clean energy project and other industrial field.
We have ability of providing workable solutions to support clients to be awarded with shorter project execution time, fewer man-hour cost and higher efficiency construction/fabrication method and better quality during phase of project bidding.Based client's facility/site space availability, we are able to study/design and present matched configurations on project schedule, quality, cost and productivity to guarantee production pace is accordance with project requirement.To support project execution, we are always ready to work as fireman to give prompt supply on project materials from different consumables, tools, equipments/machines to special merchandise. With flexibility, we are also glad to perform as procurement agent in China to seek required supply resources.
V, What we can bring to you?
1, Support you to win the project during bidding phase. We can provide your more suitable configurations to help you shorten the constrcution time.
2, We can provide all technical documents and advices to support you for construction procedure clearifications
3, We can support you to calculate the roughly construction time based one welding efficiency, the calculation of manpower needed, welding consumbles quantity
4, We can provide your suitable welding consumbles with much more competetive price from our long time business partner if you need.
5, We can provide site people training service, and operation service or manpower service or as a subcontractor.

---
