Product Details
Product Description
Product Description
The ISUZU 14-meter high-altitude operating vehicle adopts a telescopic straight arm structure. The operating arm is a 3-section telescopic type. The turntable can be operated or remotely operated. It can rotate 360 degrees, four hydraulic outriggers, and the maximum load-bearing bucket. 200 kg, stainless steel hoarding, pattern anti-skid walking platform.
2. The working bucket adopts mechanical self-balancing design, its function is that the working bucket is always in a balanced state when working. The maximum extension angle of the forearm is up to 80° in order to adjust to the best working position.
3. Night work lights, operation lights can be installed on the operating table according to the customer's operating environment, making night work safer.
4. Computer control, automatic limit, dangerous work alarm, excellent safety performance. There is a display when getting off the car, which can display the working conditions of the whole car in real time.
5. The hexagonal working arm increases the strength, synchronously expands and contracts, the structure is compact, the working efficiency is high, and the working range is large. The telescopic oil cylinder is installed externally, and the chain telescopic mechanism is easier to observe the fault point and convenient for maintenance.
6. The outrigger adopts the front V and rear H-shaped structure, which has a larger bearing surface and higher stability; it can prevent the car beam from being deformed or broken. The outriggers are individually adjustable, and each outrigger can be adjusted separately according to the working ground environment. Even if the ground is uneven, the whole vehicle can be adjusted to a stable state. All outriggers are equipped with outrigger flashing lights for supporting during operation. The legs are profiled and a light alarm signal is issued.
7. The four vertical outrigger cylinders and the upper arm, lower arm, and forearm cylinders are all equipped with two-way hydraulic locks. The function is to lock the cylinders in place after reaching the required position to prevent accidents. The working arm is equipped with a two-way balance valve to make the working arm run more smoothly.
8. The main components of the vehicle including two-way hydraulic lock, two-way lock balance valve, hydraulic flow valve, hydraulic cylinder, engine start-stop emergency pump, operating system and control computer are all domestic well-known brands, and the core components are imported. Stable commutation, flexible and convenient operation; outriggers and working arms are interlocked, safe and reliable, to prevent misoperation.
Main technical parameters of ISUZU Brand 600P 4*2 LHD diesel 14m telescopic aerial working platform truck manufactured by Chengli Special Automobile Co., Ltd. as below.
Item
| Name
| Specification /model
|
1
| Truck name
| CLW brand telescopic aerial working platform truck for sale
|
2
| Truck model
| CLW
|
3
| Truck chassis
| ISUZU
|
4
| Working height
| 14m/16m/17.5m
|
5
| Main technical parameters
| Flatform ground height≥12.3m/14.3m/15.3m
Flatform max working range: Open-ended
Flatform working height at the max working range: Open-ended
Platform max working range at the max working height: Open-ended
Plafrom max working Angle of Tilt: 80°
Rated mass of the working bucket: 200kg
|
Outriggers
| Type: Front V + rear H type, Individually control
Outriggers nos. : 4
Control: Individually control or Linkage control
Transverse Span of front outriggers: 4170mm
Gradient: 120°
Transverse Span of rear outriggers: 3930mm
|
Main operation
| Operation positio: revolving stage,Teleportation
Control type: ZYK Bus control system，electro-hydraulic proportional control system, realize stepless speed regulation
|
6
| Coaming and platform
| Stainless steel fence and Non-slip platform
|
7
| Boom construction mode
| Three-section six-sided working arm，Synchronous scaling
|
8
| Rotator device
| Two-way 360° continuous rotation, 360° hanging basket
|
9
| Engine model
| 4KH1CN5HS 96KW/130hp diesel engine
|
10
| Overall dimension(L*W*H)
| 7930×2000×2960
|
11
| Total mass
| 6265kg
|
12
| Curb mass
| 6040kg
|
13
| wheelbase
| 3360mm
|
If you're interested in our aerial working platform truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: 0086 13329899995.
More pictures of ISUZU brand telescopic aerial working platform truck is as below.
HOT SALE! ISUZU telescopic aerial working platform vehicle for sale
ISUZU 14m telescopic aerial working platform truck adopts ISUZU 600P double-row driver cab with air conditioner and power steering, 3360mm wheelbase, ISUZU 4KH1CN5HS 130hp diesel Euro 5 engine, Isuzu MSB 5 speed gearbox, 4.8tons rear axle, 7.00R16 rail tires, Double circuit oil brake, etc.
The upper part of ISUZU 14m telescopic hydraulic bucket truck as below.
The working height is 14 meters, with four hydraulic telescopic legs (up and down extension and horizontal extension), a total of 12 oil cylinders, the legs are front V and rear H type, emergency pump, bucket belt 360 degrees Rotation, wireless remote control, and others are prepared according to factory standards.
3. Introduction and performance characteristics of aerial work trucks:
1. Function introduction:
Chengliwei straight boom aerial operating vehicle has operating heights of 12 meters, 14 meters, 16 meters, 18 meters, 20 meters, 21 meters, 28 meters, 29 meters, 45 meters, telescopic working boom, large outrigger span, stability Good, can be operated simultaneously or separately, safe and reliable, compact structure, convenient operation, fast lifting speed, high work efficiency. It is flexible and can work flexibly in tight high-rise buildings. It is the leader of aerial work vehicles and leads the new trend of the industry. It is widely used in installation, maintenance and climbing operations in such industries as municipal administration, electric power, street lights, advertising, communications, photography, gardening, shipbuilding, transportation, docks, airports and ports, emergency rescue, and large industrial and mining enterprises.
>>
