Either vertical or horizontal 4-stataion or 6-stataion tool post as well as gang tool can be selected. The post is located on precision contrite gears with a high repeated positioning accuracy.
| Item | Unit | CK6130 |
| Processing | | |
| Max.cutting Dia. for disc parts | mm | 300 |
| Max. cutting Dia. for axle parts | mm | Ø135/Ø100(Gang tools) |
| Max.workpiece length | mm | 500 |
| Max. turning length | mm | 390 |
| 6-way turret Max. turning length | mm | 280 |
| 6-way turret Max. turning diameter | mm | 185 |
| Spindle | | |
| Spindle nose | | D4 or A2-5 |
| Spindle bore | Ø | Ø38 or Ø43 |
| Taper of spindle hole | | MT.No.5 or40° Taper |
| Steps of spindle speed | | Stepless |
| Range of spindle speed | rpm | 200~3500 |
| Feed | | |
| Rapid feed for axis Z | m/min | 10 |
| Rapid feed for axis X | m/min | 8 |
| Travel | | |
| Max. travel of axis Z | mm | 460(18") |
| Max. travel of axis X | mm | 165/260(Gang tools) |
| Turret | | |
| Tool post stations | | Gang tool post or power tool post |
| Tool cross section | mm | 16×16 |
| Tailstock | | |
| External diameter of tailstock sleeve | mm | 50 |
| Taper of tailstock sleeve | | MT.No.3 |
| Max. travel of tailstock sleeve | mm | 130 |
| Others | | |
| Min.input | | 0.001 |
| Power of main motor | kW | 3 |
| Power of cooling pump | W | 120 |
| Overall dimensions (L×W×H) | mm | 1500×945×1380 |
| Net weight | kg | 1100 |
