Woodworking Wood Board Furniture Wire Brush Relief Drawing Machine

Product Description

Relief Drawing Machine

Model	LZLS600	LZLS1300
Max. working width	600mm	1300mm
Max working thickness	5-90mm	5-90mm
Feeding speed	5-30m/min	5-30m/min
First unit power	7.5kw	11kw
Second unit power	1.1kw*3	1.5kw*4
Third unit power	5.5kw	7.5kw
Fourth unit power	4kw	7.5kw
Fifth unit power	4kw	5.5kw
Feeding power	2.2kw	4kw
Lifting power	0.37kw	0.75kw
Oscillating power	60w*5	60w*5
Total power	27.17kw	42.55kw
Overall dimension(LXWXH)	3500x1650x1750mm	4100x2700x1750mm
Weight	2300kg	4200kg

1 This machine is special designed for the flat products which need surface relief drawing result like archaize floor, furniture, table-board, handicraft etc and it's a new generation products processed by this machine, the flat surface is skid free, stereoscopic and beautiful
2 Conveyor belt, drawing rollers and polishing rollers all use independent controlled imported motors and the feeding use frequency conversion, which make the surface effect better and more precision controlled.
3. Drawing rollers, polishing rollers can be easily removed or remounted with precise positioning The height is read by the meters, easy to operate
4 Each unit has oscillating device, which make the work pieces more clear Each unit of roller or brush discs can be lifted independently
5 Different quantities vertical brush discs, Wire drawing rollers and polishing rollers can be equipped at different types of machines based on different materials.
Validity: 20 Days
Payment: 30% by T/T deposit in advance as down payment, balance by T/T before shipment.
Package:Plastic film package
Delivery: 30 days after receive the down payment.
Warranty: Machine supplied quality guarantee period is: one year for mechanical parts and three months for electrical parts. Warranty is counting from the date of B/L.
Installation: If need to install, the buyer bear round-trip ticket from China to buyer site, Visa fee, food, accommodation and local transportation of seller's engineer, plus USD100.00 service fee per engineer per day.

---
