Welcome to visit

Full Automatic Big China Cpet Machine Biscuit Tray Forming Hftf-82c

Negotiable 1 SET (MOQ)

Basic Info.

Model NO.
HFTF-82C
Column number
Four Column
Molding Method
Pressing
Automatic Grade
Automatic
Suitable Material
PP, PS, Pet, PVC, PLA/etc
Driven Type
Cam
Transport Package
Sea-Worthy Packing
Specification
CE Certificate
Trademark
HENGFENG
Origin
China
HS Code
84775900
Production Capacity
35cycles/Min

Product Description

Multi Function Plastic Tray Egg Food Container Plate Vacuum Flower Pot Thermoforming Forming Machine for OPS PP PS PET Material
Application
Thermoforming Machine are mainly produce upscale plastic containers like bowls,square boxes,lids,trays,etc. It is suitable for PP,PS,OPS,PVC,PETand PLA
material.
Feature
Have four stations:Thermoforming-Punching-Cutting-Stacking.
All movements driven by servo motor.
Feeding,forming,cutting and stacking processing are compete production automatically.
Mould with rapid change device,easy maintenance.
Forming with 6bar air pressure and vacuum.
Maximum speed 50 cycles per minutes.
Main Specification
Therforming Station
Max. tool size HFTF-82C/3
Max. tool size with pneumatic clamp frame 750x560mm
Max. pos/neg depth 120/120mm
Max. sheet width 820mm
Max. sheet length 620mm
Clamping force 750 KN
Sheet Thickness Range 0.2-2.5mm
Max. Speed 50Cycles/min
Upper/Lower heating 55/55 KW
Punching Station
Max. punch dimensions 750x560mm
Platen clamping force 350KN
Upper/Lower platen stroke 140/140mm
Cutting Station
Max. cut dimensions 750x560mm
Platen clamping force 750KN
