Quality 2-Head Liquid Oil Sauce Aseptic Bib Filling Machine with Capping

Product Description

Introduction: 1. Quality 2-head liquid oil sauce aseptic bib filling machine with capping is especially designed for various liquid bag-in-box filling capping production. It only needs labor to put bagneck into filling slot, then one-button to start the auto filling capping production, it can auto finish cap-removing, auto filling, auto cap-pressing & than auto bag pushing, with 2-head running, very convenient and much more efficeint. The monoblock design is less space-taking & delicate.
2. Adopting servo rotor pump filling system to do liquid filling, suitable for filling various liquid, viscous and paste materials, such as grape wine, liquor, edible oil, fruit juice, additives, milk, syrup, alcoholic beverages, concentrated seasonings and various liquid detergent, shampoo, lotion etc.
Optionally filling by flowmeter dosing, it can fill less visous liquid, easy to use, with great flexbility and efficiency.
3. All filling contacting parts are quick-released and sanitary, easy to wash and maintain.
4. With PLC, touch screen, & servo filling control, it's very easy to operate & maintain, practical & stable. automatic universal 2-head liquid gel sauce shampoo BIB filler by servo pump filling & capping Technical parameters: (professional customized for u)

Name	auto aseptic bib liquid paste filling machine
Filling capping head	1-nozzle filling & 1-head capping	2-nozzle filling & 2-head capping
Filling way	servo rotor pump filling (optional flowmeter filling based on material)
Filling scope	1-30kg (customized 20-200kg)
Capacity	1-3 BPM	2-5 BPM
Filling error	±0.5%
Air pressure	0.5-0.7MPa
Voltage	220V 50/60Hz 1P
Noise
Machine Power	1Kw	2KW
Dimension abt	L800×W900×H1750mm	L1500×W1000×H1750mm

lliquid gel cream paste bib filler, automatic universal BIB aseptic filling capping machine details fyi
2-head aseptic BIB filling capping machine, customized for different caps
3kg hot liquid juice bag filling capping fyi sanitary filling nozzle for liquid wine jam fyi
liquid jam BIB filler, 20kg bag-in-box liquid jam servo pump filling machine details fyi
liquid wine juice BIB filling machine with flowmeter filling fyi; Our BIB fillers for different packages & caps
.
professionally customizing based on specific materials, bottles/bags, caps, production process, plant layout & capacity
auto 2-head liquid bag servo filling capping machine with servo pump filling + servo capping fyi
auto 1-head liquid bag servo filling capping machine with servo pump filling + servo capping fyi
Auto servo pump bottle liquid cream filling machine with capping labeling line fyi
Baoneng Factory ISO cerficate & pump filling capping patented certificates fyi
Automatic squeeze bottle tomato paste filling machine with servo bottle capping machine line before delivery fyi
glass bottle feeder + UV sterilizer + auto juice sauce filling + vacuum capping machine + labelling in our factory fyi
Automatic plastic jar paste filling + sealing capping labeling machines before delivery from us fyi
Automatic plastic buckets/can tomato paste filling + sealing capping before delivery from us fyi
Packaging before delivery & container loading glimpse in our factory fyi
Meticulous design, Technical Innovation, Rigorous Manufacturing & Attentive servic
auto butter/magarine can feeder + washing + weighing filling + seaming + lid pressing + packaging etc
Quality First, User First, Integrity First is always Baoneng's Business Philosophy
welcome to visit our factroy in Guangzhou, China, contact Tinna for more :)

---
