| Item | RDMF-X200 | ||
| Power | 13.2 kw | ||
| Feed motor | 130BYG350(35N.m) | ||
| Spindle speed range(r/min) | 110/140/190 Spindle can option stepless speed change | ||
| Sealing surface angle | 4°-6° / Can customized | ||
| Spindle end face tapper | 1:20 | ||
| Max.processing diameter (mm) | 350 | ||
| Travel (mm) | Z: 350 X: 150 | ||
| Rapid (mm/min) | Z: 3000 X: 3000 | ||
| Repeat position (mm) | Z: 0.01 X: 0.015 | ||
| Processing Range | Gate valve DN50-DN300 | ||
| CNC system | Domestic | ||
| Lubrication system | Centralized lubrication of electronic lubricating pumps | ||
| Fixture type | Hydraulic clamping |
