4 Cavity Automatic Blow Molding Machine

Product Description

1.Specification of blowing machine
Semi-automatic blow moulding machine(L-BS510-4-R) 1)100ml-1.5L PET bottles 2)1800-2200pcs/hr 3)Germany FESTO components 4)CE
Brief introduction
L-BS510-4-R(4-cavity) Automatic blow moulding machine is suitable for producing bottles from 100ml-1.5L in 4 cavities. It is suitable for PET/PP material and is widely be applied to produce mineral water, carbonated drink, beverage,medicine, cosmetic,detergent ,oil bottles etc.It works like automatic, but with cheaper price.
A complete production line of L-BS510-4-R(4-cavity) includes:
-Main machine
-air filter(2pcs)
-High pressure air compressor(1.2cbm/3.0Mpa)
-Bottle mould(below/ 1L)
-Spare parts

The components of the machine:
PLC------------------------------------------------Bothfit
Pneumatic Components--------------------FESTO (Germany)
Transducer--------------------------------------YWJ-01D5L2(China)
Temp. controller-------------------------------CHINT
Relay----------------------------------------------CHINT
Pipe connecting part------------------------Shanghai
Seals----------------------------------------------Italy
The spare parts for L-BS510-4(4-cavity):
1) Infrared light pipe -------------------------16pcs
2) Air pipe ---------------------------------------5 meters
3) High pressure blowing valve---------- 1pc
4) Fan-------------------------------------------- 2pcs
5) High and low pressure air pipe------ 2pcs
6) Menu----------------------------------------- 1pc
7) Voltage regulator -----------------------1pc
8) Pressure meter ---------------------------1pc
9) Cylinder repair group------------------- 10pcs
10) Seals ---------------------------------------2pcs
11) Indicator light---------------------------- 1pc
12) Tools---------------------------------------- 1set


Technical data

Output	1800-2200pcs/hr
Bottle size	100ml-1.5L
Max length of bottle	340mm
Max diameter of bottle	100mm
Max mould plate size	500*380mm
Max mould thickness	110*220mm
Clamping force	180KN
Mould openning stroke(adjustable):	200mm

2.Pictures of machine:

3. Certificate of machine
4.Packing
5. Factory and Workshop
6. Exhibition
7.Customer visiting
FAQ: 1. Q: Are you a factory or trading company?
A: We are a factory.
2. Q: Where is your factory located? How can I visit there?
A: Our factory is located in Taizhou City, China. You can fly to Ningbo airport directly. All our clients, from home or abroad, are warmly welcome to visit us!
3. Q: How can I get some samples?
A: We are honored to offer you samples.
4. Q: How does your factory do regarding quality control?
A: "Quality is priority. We always attach great importance to quality controlling from the very beginning to the very end. Our factory has gained CE authentication.
Why Choose us? About us:
Zhejiang Lebao Plastics Equipment Factory, established in 1988 and registered in 1993, is a professional manufacturer and exporter of PET preforms, plastic blow molding machines, PET bottle and injection molds. It is located in Huangyan of Zhejiang Province, a city on the East China Sea well-known as "the Town of Plastic Mold".
Boasting professional technicians with rich practical experience in macromolecule field, we have been devoting ourselvers to the development of 3&5 gallon water preforms and small-sized preforms, PMMA lamp covers etc. We mainly engage in the injection, stretching, blowing (stretch technology) production of plastic products which have extensive applications in foodstuff and drink packaging, pesticide packaging, outdoor lighting as well as other daily commodities.
Over the past years, we have been entitled the "contract-stressing and promise-keeping enterprise" and our products have been awarded the "excellent scientific and technological products of Zhejiang Province".
We are located in Huangyan, the renowned land of orange in China. Since China's reform and opening to the outside world, Huangyan has developed into a famous town of mould and plastic industry.
Our people will take the opportunity to follow the business philosophy of "science and technology-based, market-oriented, take the quality as important as our own lives and the customer's benefits top everything", trail the international advanced technology and March toward the goal of mass production, internationalization and diversification.
And we warmly welcome friends from all over the world to visit our factories for business.
