Mortar Plastering Machine with Mixed Pump for Dry Material

Product Description

WUXI KONSTANT POWER TECH CO., LTD.
KONSTANT is one of main manufacture in China mainland, who specialized in professional mini dumper. Our products range from gasoline mini dumper to diesel mini dumper, battery power mini dumper and light engineering machinery.
With more than 30-year experiences on mechanic products, we have developed our customer service system with strong competition, which features as follows:
R&D Capability
KONSTANT has a 10-person R&D team, including engineers in mechanic & electronic fields. To support our customers, we develop and launch more than 3 new models annually, keeping them having strong competitive capability & always at the forefront of the market trends.
Quality Control
KONSTANT has been striving to always ensure quality products, competitive price and better service for customers at home and abroad. We are continuously investing great deal of time and capital in R & D. This allows us to be very selective in products that we manage. Quality consistency and after-sale warranty ensuring customers can be confident in their purchase expectations, be they large or small.
Fast Response
We always supply 10-day sample delivery, 35-day general order delivery and 25 days for tooling developing. Our professional product manager and export manager stand by to give you professional technical and commercial supports within 24 hours after your question.
Mortar Plastering Machine with Mixed Pump for Dry Material

Model No.	KT-G5
Power Voltage	380V-50Hz
Screw Motor Power	5.5KW
Worm Pump	D6.3 standard
Mixer Motor Power	0.75KW
Mixer Capacity	110L
Air Compressor Power	0.9kW; 250L/min
Water Pump Power	0.37KW; 60L/min
Max. Aggregate Size	4mm
Output	22L/min
Delivery Pressure	25 bar
Delivery Distance	50m
Delivery Height	20m
Weight	265KG
Dimensions	680/1190/1560mm
Noise Level	<80 dB (A)

General Information
KT-G5 is a three phase mortar plastering machine, ideal for dosing, mixing pumping and spraying different dry ready mixed materials form bag or silo. It is introduced German Technilogy, with high performance, low noise. It can continuously mixing and spraying the pre-mixed day mortar.
Usages and Features
Automatic mixing, water metering, spraying one machine. Particularly suitable for bagged dry powder materials (such as: gypsum base, cement-based, lime-based plaster, insulation mortar, etc.)
Applications
Internal Plasters: gypsum, gypsum-lime plaster
External coatings: lime, lime/cement, ETICS and insulating plaster
Self-levelling floor screeds
Versatility and easy maintenance
Wear and tear components are interchangeable universal types.
A series of interchangeable pumps are available depending on the type and granulometry of the dry mix material to be used.
It can be disassembled into parts to facilitate the transportation on the floor.
Standard Configuration
Diaphragm type air compressor,
self-priming pump,
wedge closing device for the pump
Cell dosing hopper
Electric Control Board
Screw pump(rotor and stator D6.3)
Ceaning set(scraper with rod, washing sponges)
15m mortar rubber hose Φ25mm with cam-lock coupling
16m air hose Φ13mm with quick coupling
Spray gun Φ25
Tool box, series of nozzles and connector for water hose cleaning
Other Series of Mortar Plastering Machines
Loading
Delivery
1. Normal Delivery Time: 30-45 days after deposit. If in hot sale season, please confirm with us before ordering.
2. Batch Selling and Retail: We do batch selling to shops, rental center, trading company, dealers etc... They will do aftersales service for us.
We do not do retail as it is not economic for both us and the retail customers.
3. OEM and ODM is available.
4. Payment Term: Negotiation.
5. Warranty: 12 month after leaving factory.
6. Dealer-ship: We do offer dealer-ship and dealer numbers will against the market situation. And we will have our own dealer management and marketing system.

---
