Foton Rice Harvester Dg200 Combine Harvester Farming Machine

Product Description

FOTON Agricultural Machine Rice Harvester DG200
Engine: YC6B110-T20(73.5KW\2100r/min),
Cutting Width: 3.25m,
Grain Tank Capacity: 2.5m3,
Discharging Cylinder.

Parameter Items	Parameter Value
Engine powerps	75
Cutting widthmm	2000
Feeding in volume (kg/s)	2
Total loss rate()	Wheat≤ 1.5 Rice≤ 3.5
Broken rate ()	Wheat≤ 2.0 Rice≤ 2.0
Impurity rate ()	Wheat≤ 2.0 Rice≤ 2.0
Threshing and cleaning structure	Feed-in wheel+ single horizontal axis flow roller
Gravure plate adjustable structure	adjust the position of threshing teeth
Axial-flow cylinderouter diameter× lengthmm	620× 1854
Grain tank capacitym3	0.42
Grain Unloading type	manual receiving grain
Caterpillar specification	400× 90× 49
Running speed range	08.579
Operating weight (kg)	2900
Overall Dimensions(L*w*H mm)	≤ 5115× 2290× 2800

*********************************************************************************
