Product Details
Product Description
Product Description
Automatic Ice Cream Machine With different volumes 18L 20L 32L 42L 52L
Automatic ice cream machine With different volume 18L 20L 32L 42L 52L, it is the best machine to work with the Automatic waffle cone making machine.
Advantages of Automatic ice cream machine:
1. Upgrade puffing function, fine and silky texture, increase yield
2.LCD touch panel
3. Low cost, high profit. Ice cream machine output 20L per hour, 5kg ice cream powder can make more than 200 ice creams.
4.Food grade stainless steel tank
5. Full copper pipe freezer
6. High-power compressor, higher efficiency, longer life usage
Working Principle:
Firstly, the raw materials of ice cream are added into the raw material cylinder, under the action of air milk pump,
the raw materials and air are mixed evenly and transported to the freezing cylinder. In the freezing cylinder, the
milk slurry is cooled down by the refrigeration system while being stirred by the mixing scraper rack, and the
viscosity of the milk slurry increases gradually as the temperature decreases. When the current of the mixing
motor reaches the set value, it means that the ice cream reaches the required viscosity, at this time, the
compressor of the refrigeration system stops working, the mixing motor also stops working, the ice cream
production is completed, and it can be extruded through the outlet.
Parameter data:
| Model | AJ-L18B | AJ-L18A | AJ-L20N |
| Version | Vertical | Desktop | Vertical |
| Quality | SS304 | Color painted |
| Voltage | 220v 50hz 1phase | 220v 50hz 1phase |
| Power | 1.9Kw /12A | 1.85KW |
| Electric consumption | 23kwh/24h |
|
| Refrigerant | R22 |
| Raw material Tank | 4.3L*2 |
|
| refrigeration cylinder | 1.5L*2 |
|
| Capacity | 18L/H |200pcs/h | 20L/H |
| Continuous press | 15-20pcs |
|
| Dimension | 506*575*1280mm | 506*575*850mm | 504*705*1177mm |
| N.W. | 90KG | 80kg | 98KG |
| Wooden case dimension | 570*640*1380mm | 570*640*930mm | 604*805*1380mm |
| G.W. | 100KG | 90KG | 108KG |
| Note: we also have larger capacities like 32L, 42L, and 52L, please talk with us about your detailed demands. |
>>
