Product Description The plane UV curing machine is used for solidification after printing UV inks printing UV inks. The UV curing machine is usually composed of a conveyor belt and a UV curing system that can be transmitted. The products after printing ink enter the UV curing unit as the conveyor belt enters the UV curing unit and receive the UV light. Product surface. Choose the UV curing machine mainly to consider the width of the conveyor belt. To ensure that the product can be placed on the conveyor belt without any interference. The power is the main factor that determines the drying speed of the UV: multiple lamps or larger power drying speeds will be faster, and the speed of the conveyor belt can be adjusted faster, but the power of the unit distance is too much. If you are too high, we must weigh the advantages and disadvantages. Click to learn more....
M-3000LEDUVS Cylinder UV Drying Machine//Usage and characters
|
Guide
| It is mainly used for drying the ink layer after printing UV ink on hollow bottle products made of various plastics, metals and glass; Compact structure, high curing efficiency, widely used in cosmetics, plastic packaging and other industries; The bottle can be automatically rotated after entering the curing unit, so that the UV light can completely irradiate the surface of the bottle and improve the curing efficiency; Stainless steel sheet conveyor belt, better temperature resistance; At present, the more environmentally friendly ink drying method; A light-emitting diode is used to light up and emit ultraviolet light with a main peak of about 400 nm, and the acrylic resin of the ink is irradiated on the ink layer to cause cross-linking and curing of the ink. Water cooling system is adopted to improve the service life of LED UV light source. |
Application fields
| Electron, Hardware, Auto, Toys, Gifts, Plastics parts, Plastics products, House appliances, work of art, Stationery, Ornament, cosmetic, sports apparatus .UV drying for UV ink . |
M-3000LEDUVS Cylinder UV Drying Machine//Parameter
|
Technical parameters
| Max. curing size of workpiece: Cylinder:300X200mm Conveyor speed:0~10m/min ; Total power:3.5KW; Outline dimension:2100X600X1700mm ; Conveyer width: 400mm; LED Lamp Wattage: 2*1500W; Power supply: 1 Phase 220V. |
Works supply
| Power: 1 phase 220V. |
Package list
| Package dimension:2.250×0.870×1.900m; Gross weight:330KG; CBM: 3.7193 |
H.S.Code
| 8443198000
|
Certificate
| CE
|
M-3000LEDUVS Cylinder bottle UV Curing Machine//Advantage
|
Function
| Stainless steel conveyor belt, high temperature resistance; Driven by a famous brand motor, the speed can be adjusted steplessly, which is convenient to adjust the conveying speed according to the product characteristics; LED UV light source, the surface temperature of the product is low, and the product is not easily deformed during the curing process; No need for high pressure excitation, high safety performance, saving tender tubes With a water cooling system, it can effectively reduce the temperature of the LED tube and improve the service life; UV ink light curing for the surface of round objects improves the light curing effect of round objects. |
Main configuration
| Operation panel LED UV system Water cooling system Conveyor and rotating device |
Accessories included
| Operation instruction in English; |
