Ecoographix G460b Gathering Machine/ Binding Machine

Product Description

G460B Automatic Gathering Machine and Binding Machine
G460B automatic binding machine ensures high net output. The gripper system and the vertical transport of signatures are combined in this machine with modern electronics and latest design. It can be used either as a stand-alone machine or connected in-line with Challenger-5000 Perfect Binder.
Features
Reliable and non-marking separating of sections thanks to the vertical gathering design.
Touch screen allows easy operation and convenient fault analysis.
Comprehensive inspection system for miss-sheet, double-sheet and paper jams.
Easy changeover between 1:1 and 1:2 production modes brings high flexibility.
Criss-cross delivery unit and hand feeding station are offered as standard features.
Reject gate for wrong signatures ensures non-stop production.
Excellent quality control is enabled by the optional signature recognition system. Specification

Model	G460B/8	G460B/12	G460B/16	G460B/20	G460B/24
No. of Stations	8	12	16	20	24
Sheet Size (a)	196-460 mm
Sheet Size (b)	135-280 mm
In-line Speed	Max. 8000 cycles/h
Off-line Speed	Max. 4800 cycles/h
Power Required	7.5 kw	9.7 kw	11.9 kw	14.1 kw	16.3 kw
Machine Weight	3000 kg	3500 kg	4000 kg	4500 kg	5000 kg
Length of Machine	10736 mm	13022 mm	15308 mm	17549 mm	19886 kg

Producing and Packaging
From producing to delivery, we make every details very carefully to guarantee the good product quality and service to customers.

Certificates
FAQ
1. Payment term?Down payment 30% of the total payment shall be made by T/T once order is confirmed and the balance shall be paid by T/T before delivery. 2. Installation and after service?Conditional and prior to mutual agreement between the seller and the buyer.3. Warranty?12 months from the date of arrival at the port of destination. Damages caused by faulty operation do not fall under warranty wear and tears parts are not under warranty.4. Package?Seaworthy packaging (vacuum packed with aluminum foil in wooden cases).

---
