| US$57.00 | 100 Pieces (MOQ) |
| 4G Module information | |||||
| LTE Module Model | Quectel EC25, LTE-CAT4 Quectel EC20, LTE-CAT4 Quectel EC200, LTE-CAT4 | ||||
| Band Support | GSM/WCDMA/LTE-FDD/LTE-TDD | ||||
| LTE Data Rate | LTE-FDD: max 150(DL)/Max 50(UL) ,LTE-TDD: max 130(DL)/Max 35(UL) | ||||
| Name | Details | ||||
| CPU | MT7628 | ||||
| FLASH | 8MB | ||||
| SDRAM | 64MB | ||||
| Name | Details | ||||
| LAN | 3*10/100MBase-T LAN, support IEEE 802.3/802.3u auto-negotiation | ||||
| WAN/LAN | 1*10/100MBase-T WAN/LAN, support IEEE 802.3/802.3u auto-negotiation; It is LAN port when work as 4G Router, WAN port when work as wireless router Support PPPoE, Automatic IP, Static IP, PPTP, L2TP, 4G | ||||
| 4G Antenna Connector (Selective) | External Female SMA Connector, Impedance 50Ω | ||||
| WIFI Antenna Connector | External Male SMA Connector, Impedance 50Ω | ||||
| SIM Card Slot | Support SIM Card Slot | ||||
| RESET | Press it 10 seconds, Reset to factory default | ||||
| LED Light | WAN, LAN, Wi-Fi, System | ||||
| RF Power | 802.11b | 11M | 17±2dBm | 1M | 19±2dBm |
| 802.11g | 54M | 16±2dBm | 6M | 18±2dBm | |
| 802.11n HT20 | MCS7 | 15±2dBm | MCS0 | 17±2dBm | |
| 802.11n HT40 | MCS7 | 15±2dBm | MCS0 | 17±2dBm | |
| Receive Sensitivity | 802.11b | 11M | -85dBm | 1M | -94dBm |
| 802.11g | 54M | -72dBm | 6M | -90dBm | |
| 802.11n HT20 | MCS7 | -70dBm | MCS0 | -88dBm | |
| 802.11n HT40 | MCS7 | -68dBm | MCS0 | -86dBm | |
| EVM | 802.11b: ≤-10dB ; 802.11g: ≤-25 dB ; 802.11n: ≤-28 dB | ||||
| PPM | ±20ppm | ||||
| Channel | 1~13, Support auto channel | ||||
| Standard | 802.11b/g/n | ||||
| Bandwidth | HT20, HT20/HT40 | ||||
| Security | Open System, Shared key, WPA-Personal, WPA2-Personal, WPA-Auto-Personal, WPA-Enterprise(Radius), WPA2-Enterprise(Radius), WPA-Auto-Enterprise(Radius), Radius with 802.1x | ||||
| RF Power Adjustable | Support | ||||
| Name | Content | ||||
| Working Temperature | -30ºC ~ +55ºC | ||||
| Max Working Temperature | -40ºC ~ +85ºC (Throughput some decrease) | ||||
| Storage Temperature | -40ºC ~ +70ºC | ||||
| Humidity | 5%~95% (No Condensation) | ||||
| Name | Content | ||||
| Wi-Fi | Support Auto Channal, Guest SSID, SSID hide, Wireless MAC filter, white and black list | ||||
| Net | PPPoE, Automatic IP, Static IP, L2TP, PPTP, 4G | ||||
| Support automatically switch between WAN/ISP and 4G | |||||
| Support VPN server and VPN client: PPTP, L2TP and OpenVPN | |||||
| Support AP+Client | |||||
| Firewall | Support NAT, URL Filter, MAC Filter and Network Service Filter | ||||
| Support DoS attack protection, SYN flood attack | |||||
| WAN PING,SSH, HTTP Access | |||||
| Other functions | NTP and account setup; Port forwarding,Virtual Server,Watchdog,DMZ,DDNS | ||||
| Item | Specifications | |
Antenna | Frequency Range | 2.4GHz~2.5 GHz |
| Gain | 5dBi | |
| V.S.W.R | ≤1.9 | |
| Impendance | 50Ω | |
| Polarization | Vertical | |
| Radiation | Omni | |
