Product Details
Product Description
Product Description
Overview Quick Details
Place of Origin:Liaoning, China
Brand Name:GCAN
Model Number:USBCAN modul 8
Operating Voltage:24V
Isolation voltage:1500V Magnetic coupling isolation
Interface form:DB9
CAN baud rate:5K~1Mbps
Elctronic Isolate:1500V
CAN channels:8
Packaging & Delivery
Selling Units:Single item
Single package size: 26X16X6 cm
Single gross weight:0.500 kg
Package Type:Export carton
Lead Time:
| Quantity(sets) | 1 - 500 | >500 |
| Est. Time(days) | 7 | To be negotiated
|
Description
USBCAN-Modul 8 is a high-performance CAN-Bus communication interface card integrated with 8-channel CAN interface.This model CAN card is compatible with the full speed specification of USB2.0 Bus, using the USBCAN-Modul8 high-performance CAN interface card, PC CAN be quickly connected to the CAN-Bus network through USB interface.
|
|
|
USBCAN-Modul 8 high performance CAN interface card supportWindows XP/Win7/Win10 Linux and other operating systems,we provide a complete application demonstration code (VC VB Net Delphi Labview C++Builder), for the convenience of users for application development.
|
|
|
Software Functions
1. Transmit/Receive data
Transmitting and receiving is the basic function of ECAN Tools, in this interface, users can directly see the received CAN data, and send the data to CAN bus.
2.CAN-Bus diagnosis function
CAN-Bus diagnosis function can detect the bus error frames and bus arbitration lost.
3.Statistics mode When receiving data,software can classify these data in ID,data name, format or type and counting the number of each data.
4.Other functions Save data:save the receiving list Display mode:scroll mode and list mode, list mode can classified data togetheraccording to the rules Filter settings :user can set multi-stage filtering by editing the filter ID. Data mask:masked ID is not displayed Error frames : error frames on the bus can be displayed/hidden
>>
