Product Details
Product Description
Product Description
■General Technical Characteristics
Excellent withstand voltage, excellent behavior on pulse and fast discharge conditions.
Low dissipation factor, low partial discharge.
Coated with flame-retardant epoxy resin. Coated and uncoated devices available.
■Typical Applications
Used in electrical equipment and the pulse energy equipment of power transmission and distribution systems.
For power compensation, current limiting, filtering, metering, energy storage and voltage divider products.
■Electrical Specification & Part Numbers Reference (mm)
Capacitance
| Voltage
KV DC
| Tol.
%
| D
| H
| L
| M
| Ceramic
| Part Number
|
1000pF
| 10
| 10
| 30
| 16
| 20
| 5
| N4700
| KCT8G10KVDL102K30
|
2200pF
| 10
| 20
| 38
| 16
| 20
| 5
| N4700
| KCT8G10KVDL222M38
|
8000pF
| 10
| 20
| 60
| 16
| 20
| 5
| N4700
| KCT8G10KVDL802M60
|
370pF
| 15
| 10
| 20
| 20
| 24
| 5
| N4700
| KCT8G15KVDL371K20
|
560pF
| 15
| 10
| 20
| 18
| 22
| 5
| N4700
| KCT8G15KVDL561K20
|
1000pF
| 15
| 10
| 30
| 18
| 22
| 5
| N4700
| KCT8G15KVDL102K30
|
2200pF
| 15
| 20
| 45
| 18
| 22
| 5
| N4700
| KCT8G15KVDL222M45
|
3000pF
| 15
| 20
| 45
| 18
| 22
| 5
| N4700
| KCT8G15KVDL302M45
|
5300pF
| 15
| 20
| 60
| 18
| 22
| 5
| N4700
| KCT8G15KVDL532M60
|
280pF
| 20
| 10
| 20
| 20
| 24
| 5
| N4700
| KCT8G20KVDL281K20
|
1000pF
| 20
| 10
| 30
| 20
| 24
| 5
| N4700
| KCT8G20KVDL102K30
|
2200pF
| 20
| 20
| 45
| 20
| 24
| 5
| N4700
| KCT8G20KVDL222M45
|
4000pF
| 20
| 20
| 60
| 20
| 24
| 5
| N4700
| KCT8G20KVDL402M60
|
10000pF
| 20
| 20
| 60
| 18
| 22
| 5
| Y5T
| KCT8G20KVD103M60
|
30000pF
| 20
| 20
| 60
| 18
| 22
| 5
| Y5V
| KCT8G20KVF303M60
|
400pF
| 30
| 10
| 20
| 20
| 24
| 5
| N4700
| KCT8G30KVDL401K20
|
1000pF
| 30
| 10
| 38
| 22
| 26
| 5
| N4700
| KCT8G30KVDL102K38
|
2200pF
| 30
| 20
| 52
| 24
| 28
| 5
| N4700
| KCT8G30KVDL222M52
|
3000pF
| 30
| 20
| 60
| 24
| 28
| 5
| N4700
| KCT8G30KVDL302M60
|
5300pF
| 30
| 20
| 60
| 24
| 28
| 5
| Y5S
| KCT8G30KVS502M60
|
20000pF
| 30
| 20
| 60
| 24
| 28
| 5
| Y5V
| KCT8G30KVF203M60
|
100pF
| 40
| 10
| 20
| 30
| 34
| 5
| N4700
| KCT8G40KVDL101K20
|
150pF
| 40
| 10
| 20
| 24
| 28
| 5
| N4700
| KCT8G40KVDL151K20
|
200pF
| 40
| 10
| 20
| 24
| 28
| 5
| N4700
| KCT8G40KVDL201K20
|
440pF
| 40
| 10
| 30
| 30
| 34
| 5
| N4700
| KCT8G40KVDL441K30
|
500pF
| 40
| 10
| 30
| 30
| 34
| 5
| N4700
| KCT8G40KVDL501K30
|
1000pF
| 40
| 10
| 38
| 24
| 28
| 5
| N4700
| KCT8G40KVDL102K38
|
1000pF
| 40
| 10
| 45
| 30
| 34
| 5
| N4700
| KCT8G40KVDL102K45
|
2200pF
| 40
| 20
| 52
| 16
| 30
| 5
| N4700
| KCT8G40KVDL222M52
|
2200pF
| 40
| 20
| 60
| 30
| 34
| 5
| N4700
| KCT8G40KVDL222M60
|
3300pF
| 40
| 20
| 60
| 30
| 34
| 5
| Y5S
| KCT8G40KVS332M60
|
5000pF
| 40
| 20
| 60
| 30
| 34
| 5
| Y5T
| KCT8G40KVD502M60
|
10000pF
| 40
| 20
| 60
| 30
| 34
| 5
| Y5U
| KCT8G40KVE103M60
|
15000pF
| 40
| 20
| 60
| 30
| 34
| 5
| Y5V
| KCT8G40KVF153M60
|
10000pF
| 70
| 20
| 100
| 66
| 70
| 5
| Y5U
| KCT8G70KVE103M100
|
5000pF
| 80
| 20
| 100
| 70
| 74
| 5
| Y5T
| KCT8G80KVD502M100
|
700pF
| 100
| 20
| 60
| 80
| 84
| 5
| Y5S
| KCT8G100KVS701M60
|
1000pF
| 100
| 20
| 60
| 80
| 84
| 5
| Y5T
| KCT8G100KVD102M60
|
2000pF
| 100
| 20
| 72
| 80
| 84
| 5
| Y5T
| KCT8G100KVD202M72
|
3000pF
| 100
| 20
| 85
| 80
| 84
| 5
| Y5T
| KCT8G100KVD302M85
|
Remark: Customization for special specification and requirement is available.
>>
