16CH Hybrid CCTV DVR Recorder for Ahd Tvi Cvi IP Cameras with Audio Over Coaxial Grand Stage/Architecture/Engineering/Cinema CCTV

Product Description

Product Description
16CH Hybrid CCTV DVR Recorder for Ahd Tvi Cvi IP Cameras with Audio Over Coaxial
Welcome to Veacam Electronics Co., Ltd! Introducing our latest product, the 16CH Hybrid CCTV DVR Recorder for Ahd Tvi Cvi IP Cameras with Audio Over Coaxial. This state-of-the-art recorder is designed to meet all your surveillance needs with its impressive features and capabilities.
Key Features:
Supports H.265/H.264 video formats for high-quality recordings.
Enables audio transmission over coaxial cable, ensuring clear and synchronized audio with your video footage.
Compatible with TVI, AHD, CVI, CVBS, and IP cameras, providing adaptive access to a wide range of camera types.
Offers 16-channel BNC input for seamless integration with your camera setup.
Equipped with 1-ch HDMI output and 1-ch VGA output at up to 1920*1080 resolution, allowing you to view your recordings in high definition.
Provides long transmission distance over coaxial cable, ensuring reliable connectivity throughout your surveillance system.
With the 16CH Hybrid CCTV DVR Recorder, you can trust that your security needs are in good hands. Its advanced features and compatibility make it the perfect solution for any surveillance setup.
Choose Veacam Electronics Co., Ltd for all your security camera recording needs. Our products are designed to deliver exceptional performance and reliability, ensuring your peace of mind.
Product Parameters

Model	VCXVR-516UA1S
Video/Audio Input
Analog Video Input	16-ch, BNC
IP Video Input	8-ch(only IP up to 16ch), each channel up to 8MP
Supported Analog Camera Types	Support AHD input: 5MP@12fps 4MP@15fps 1080P@30fps Support TVI input: 5MP@12fps 4MP@15fps 1080P@30fps Support CVI input: 1080P@30fps 720P@30fps Support CVBS input
Audio Input	1-ch, RCA
Network
Incoming Bandwidth	40Mbps (up to 56Mbps after all analog camera conversion)
Outgoing Bandwidth	64Mbps
Remote Users	128
Protocols	TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE
Video/Audio Output
VGA Output	1920x1080/60Hz, 1920x1080/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
HDMI Output	1920x1080/60Hz, 1920x1080/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
Audio Output	1-ch, RCA
Two-way Audio	1-ch, RCA
Synchronous Playback	16-ch
Encoding
Recording Resolution	5MP Lite/4MP Lite /1080P/1080P Lite/720P/D1/CIF
Recording Frame Rate	Main stream:	Sub stream:
	5MP Lite@6fps	D1@6fps
	4MP Lite@8fps	D1@8fps
	1080P Lite@15fps	D1@6fps
	720P@15fps	D1@10fps
Hard Disk
SATA	1 SATA interface
Capacity	Up to 6TB for each HDD
External Interface
Network Interface	1RJ45 10M/100M self-adaptive Ethernet Interface
USB Interface	Rear panel:2 x USB2.0
Serial Interface	1 x RS485
General
Power Supply	12V DC Power Consumption: ≤ 10 W( without HDD )
Working Environment	-10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing)
Dimensions(W×D×H)	260mm ×243mm× 39mm (10.1" × 9.6"×1.8")
Weight ( without HDD )	≤1.1 Kg ( 2.42lb )

Detailed Photos

Company Profile
Certifications
Our Advantages

FAQ
Introducing our High Definition 5MP True WDR Network Camera with Human Detection and Built-in Mic Experience exceptional security and peace of mind with our state-of-the-art High Definition 5MP True WDR Network Camera with Human Detection and Built-in Mic, brought to you by Veacam Electronics Co., Ltd.
With its high definition capabilities, this camera delivers crystal clear images and videos, capturing every detail with precision. The True WDR technology ensures optimal image quality even in challenging lighting conditions, providing you with accurate and reliable surveillance footage.
Equipped with advanced human detection technology, this camera intelligently identifies human movements, minimizing false alarms and ensuring that you are alerted only when necessary. The built-in microphone allows for clear audio recording, enhancing the overall surveillance experience.
Designed for outdoor use, this camera is waterproof and weatherproof, making it suitable for any environment. Its durable construction ensures long-lasting performance, even in harsh conditions. The IP67 rating guarantees protection against dust and water, ensuring reliable operation at all times.
Installation is a breeze, and this camera offers flexible connectivity options, seamlessly integrating into your existing security system. Whether you prefer DHL/UPS/Fedex or other air and sea shipments, we can accommodate your shipping preferences.
At Veacam Electronics Co., Ltd, customer satisfaction is our top priority. We offer various payment methods, including T/T, LC, Western Union, and Trade Assurance, to ensure a convenient and secure transaction process.
Customization is also available. You can print your logo on the product, making it uniquely yours. Depending on your requirements, we can adjust the minimum order quantity to suit your needs. We even support small test orders for all customers.
If you would like to experience the quality of our product firsthand, we offer samples for a fee. Rest assured, the sample fee will be refunded in your later order.
Don't miss out on the opportunity to enhance your security system with our High Definition 5MP True WDR Network Camera with Human Detection and Built-in Mic. Contact us now for more details and let us help you achieve unparalleled surveillance.

---
