| Negotiable | 1 Set (MOQ) |
| Product | Φ | A | B | C | D | E |
| KA-A3400-2E | 3400 | 2200 | 2600 | 1510 | 3566 | 1500 |
| KA-A3600-2E | 3600 | 2200 | 2600 | 1610 | 3766 | 1600 |
| KA-A4200-2E | 4200 | 2200 | 2600 | 1910 | 4366 | 1900 |
| KA-A4800-2E | 4800 | 2200 | 2600 | 2210 | 4966 | 2200 |
| Bearing capacity in the display case | <20kg |
| Withstanding Voltage | 1500V/min |
| Revolving wheel load capacity | <300kg |
| Revolving speed | 0.45 ~ 0.7m/s |
| Standby speed | 0.3 ~ 0.35m/s |
| Working Temperature | -30°C ~ 40°C |
| Wind resistance | Grade 8 |
| Power voltage | Single phase 220V±10% 50Hz |
| Total power | 1450W |
| Noise | <60dB |
| Lighting power | 500W max 12w each 35 |
| Revolving door power | 800W max |
| Sliding door power | 150W max |
| UPS power supply time | 3min |
| PLC programmable controller system | yes |
| Operation modes, Automatic Manual | yes yes |
| Windbreak, dust proof and sound insulation | yes |
| Programing parameters via integrated programable logic control system | yes |
| Read-out error memory with Error message | yes |
| Safety with Anti-bump, anti-squeeze, anti-strike | yes |
| Safety with kinds of safety sensor,etc. | yes |
| Central control with offfire protection | yes |
| Access control with radars,remote,keypad,etc | yes |
| Emergency with Disable switch,emegerncy stop switch,etc | yes |
| Rechargeable battery pack for emergency operation | yes |
| Breakout system choice | yes |
