| PET STYLE SPECIFICATION | UE/270 | |||
| SCREW TYPE | A | B | C | |
| Injection Unit | ||||
| Screw diameter | mm | 50 | 55 | 60 |
| Screw L/D ratio | L/D | 25 | 25 | 25 |
| Shot volume(theoretical) | CM3 | 530 | 641 | 763 |
| Injection weight(PET) | g | 661 | 799 | 951 |
| Injection rate | g/s | 258 | 311 | 370 |
| Injection pressure | MPA | 204 | 169 | 142 |
| Screw speed | rpm | 150 | ||
| Clamping Unit | ||||
| Clamping force | KN | 2700 | ||
| Open stroke | mm | 560 | ||
| Space between tie-bars(W*H) | mm | 580*580 | ||
| Max mould height | mm | 580 | ||
| Min mould height | mm | 200 | ||
| Ejector stroke | mm | 170 | ||
| Ejector force | KN | 70 | ||
| Others | ||||
| Max pump pressure | MPA | 16 | ||
| Pump Motor power | KW | 29 | ||
| Heating power | KW | 16.8 | ||
| Numbers of heating area | Segment | 3+1 | ||
| Machine dimension(L*W*H) | M | 6.1*1.65*2.35 | ||
| Oil tank cubage | L | 380 | ||
| Machine weight | TON | 9 | ||
| Name | Brand |
| Computer | KEBA(AUSTRIA) or EST |
| Servo Drive | INOVANCE(CHINA) |
| Servo Pump | SUNNY(USA) / SUMITOMO(JAPAN) |
| Servo Motor | PHASE(ITALY) |
| Electro-hydraulic Proportion valve | HNC (Taiwan) |
| Stroke transducer | NOVO or Miran(GERMANY)/GERFRAN(ITALY) |
| Breaker | Schneider (FRANCEN)/Siemens(GERMANY) |
| Contacts | Schneider (FRANCEN)/Siemens(GERMANY) |
| Switch | Schneider (FRANCEN)/Siemens(GERMANY) |
| Hydraulic Direction Valve | Vickers (USA) or Rexroth (GERMANY) |
| Plasticing Motor | DINAMIC(ITALY) or STF(ENGLAND) |
| Hydraulic Hose | MANULI(ITALY)/CONTINENTAI(GERMANY) |
| Plasticing speed sensor | OMRON |
| Sealing ring | HALITE or TREIIEBORG(UK or GERMANY) |
