Customize Industrial Advertising Display Indoor LCD Digital Signage Kiosk for Airport

Product Description

Customize industrial grade digital display indoor digital signage kiosk for airport.
Ideal for displaying your digital advertisements in busy areas for maximum exposure.
Main Features
· LG brand digital display screen, 500-700nits, designed for 24/7 usage
· 4K ultra high definition screens with 178°/178° wide viewing angle
· Ultra clear tempered glass with screen printing boarder, elegant full glass design.
· Auto brightness backlight control, lifetime up to 60,000 hours.
· Customize size ( 55 inch - 86 inch) and features ultra thin.
Display
4K Ultra HD 500nits 24/7 usage
· Industrial grade digital display, designed for 24/7 usage
· 4K ultra HD screens with 178 ° wide viewing angle to give vivid, sharp images.
· 16.7m display color, 9:16 4000:1 contrast ratio
· LED Direct backlit system:up to 50,000 hours
Enclosure
Robust and stylish
· The highly durable enclosure is made by welded aluminum profile, with Elegant Full Glass Design.
· Galvanize steel with outdoor powder coating, color can be customized.
· Customize logo print on glasses available.
· Secure locking system.
Anti-vandalism
The screen is covered by 6mm clear tempered glass(IK10),with ceramic printing border.
Customize backlit logo printing available, and its easy cleaning.
Smart cooling system
To enlarge the stability and lifetime of the LED screen, we built smart high-power cooling fan group inside the totem to keep the temperature in a suitable range, which can avoid the overheat inside the machine.
Safety protection
· Build in circuit breaker, provide the short circuit, overload, current leakage or over-voltage protection
· Build in SPD(surge protective device), avoid the damage from a peak current or voltage to the sensitive equipment.Operation System
Windows PC or Android OS system
· Industrial PC, Windows 10, CPU i5 4G+128G
· Android 5.1 Rockchip 2G memory +8G
· Wifi or 4G network communications
· VGA/HDMI/USB/RS232/RJ45
Smart control CMS
The smart control system based on android 11. Which allows client to control the content by PC and mobile. with the smart control CMS, clients can monitor the screens performance and condition remotely. Including temperature, power, displays. The Auto brightness control will automatically adjust the brightness according to the environment.

Specifications

Screen size	55" 65" 75" 86" Available
Panel	75 inches 500nits LCD panel (Brand LG )
Brightness	500 nits
Display area	930*1650mm
Dimensions (W*H*D)	1150*2550*170mm
Resolution(Pixels)	3840*2160
Proportion	16:9
Contrast	4000:1
Color Depth	8bit, 16.7M
Response time	6ms
Viewing angle	178*178
Display mode	Normally black
Input port	DC IN (12V,HDMI, VGA,USB,RJ45,USB,Mic- IN,Line out )
OS	Windows/ Android
Current consumption	250 W (500W double sided)
Environment Temperature	0-30
Enclosure	Front 6mm tempered glass
	Galvanize steel with powder coating color
Cooling system	High-power cooling fan system
Water proof	IP 35

Customize Design Available
· Customize size ( 55 inch - 86 inch) and features ultra thin
· Single side or double sided
· One side lcd screen, the other side poster
· Windows / Android OS
· HD camera for audience analytic
Certifications
Packaging & Shipping
FAQ
1. What are the advantages of star vision's digital signage?
With more than decade experience on the design and engineering of ooh and Dooh infrastructure, Star Vision provide our customer designs which are unique from the market to increase Dooh Media owners brands recognition.
2. How do we start?
Once client told us where to deploy the structure, we will propose several design with price for choices, and also we can make new design based on clients requirement, after confirm all the details, than we do the quotation, then we go for prototype, after get feedback or approval of the prototype, than we proceed the bulk orders.
3. Can I have my logo on the product?
Yes, customized logo service is available.
4. What about the payment terms?
30% in advanced, balance before shipment.
5. How do you pack the products?
Wooden case on pallet, which is easy to load and unload from the container, and protect the products well no matter by sea or by air.
6.How do you support us for use of the products?
We will send Installation drawing to client, and video call, phone services, email support are always available, and if necessary our engineer can visit client to guide how to install the products and train your team how to use our products, ticket, training and accommodations charges on client side.
7. What is the guarantee time?
The guarantee time is 1 year, and it can be extends to 3 years on extra charges, during guarantee period , we can repair or change defective components for client free of charge, however, delivery cost of sending components are on both side.

---
