Vmc-850 CNC Vertical Machining Center Metal Lathe CNC Milling Machine

Product Description

Product Description
The 3 axis VMC-850 is a high performance CNC vertical machining center developed and manufactured by our company. The machine has the characteristics of high rigidity, high speed and high precision and has more advantages on operation and capabilities compared with similar products. All castings of the machine have been secondary tempered to provide excellent rigidity and stability for the whole machine. This machine applied with high rigid C design on structure, it also has been done with reinforcement on machine ribs.All the contact faces have been scraped manually, which guarantees the durability of accuracy. X/Y axes apply with two types of rolling guide way: ball bearing and roller guide way, which is optional that customer can choose base on customer's needs. Z axis applies roller guide way, which enables the machine to be with high rigidity, low noise, and small friction. The machine equips with an air tank, and the water can be drained out manually. Spindle is connected directly, and the highest speed can reach 8000RPM, which make this machie as a good choice for machining some complex parts with high efficiency.
Product Parameters

Model	Specification
JT-VMC850	Control System		Fanuc 0I TF PLUS
	Table size	mm	1000×500
	Maximum allowable load	kg	500
	T-slot dimensions	mm/piece	5-18*90
	Maximum table travel - X axis	mm	800
	Maximum table travel - Y axis	mm	500
	Maximum table travel - Z axis	mm	500
	Distance from spindle face to table surface	mm	130-630
	Distance from spindle center to Z-axis guide surface	mm	540
	Tapered hole(7:24)		BT 40 φ140
	Speed range	r/min	8000
	Spindle motor power	kw	7.5/11
	X/Y/Z axis rapid feed	m/min	36/36/24
	Linear guide width and type	X axis	35mm roller
		Y axis	35mm roller
		Z axis	35mm roller
	Feed rate	mm/min	1-10000
	Tool changer type		Disk type
	Tool magazine capacity	Handle	24
	Tool change time	s	2.5
	X/Y/Z axis repeatability	mm	±0.005/300
	Overall Dimensions	mm	2700*2260*2400
	Weight	kg	5000

---
