Product Details
Product Description
Product Description
Feature
uHigh capacity
u High concentration ratio and high
recovery
u Fabricated with highest quality
material
u Easy to install, operate and maintain
u The pulsation curve is saw-tooth wave shape facilitate heavy mineral to
settling
u Saving water 30-40% than ordinary jig
u The pulsation speed very easy adjusted
by regulator
u Suitable for roughing and cleaning
u Can achieve a good result in processing
such as placer gold, tungsten,iron, tin, hematite, copper, tantalum-niobium,
titanium, manganese, barite, zirconium, chrome and gemstone etc.
Construction drawing ofJT2-2 Saw-tooth Wave Jig
Model
| Hutch
| Diaphragm
|
Feeding Size
(mm)
| Amount
of
make-up
water
(m3/t)
|
Make-up water
pressure
(Mpa)
|
Capacity
(t/h)
|
Power (kw)
|
Dimensions
(mm)
|
Weight (Kg)
|
Shape
|
Area (m2)
|
Stroke (mm)
| Frequency
of Stroke
(r/min)
|
|
|
|
8.5—12
10—17
12-21
|
80-180
| <6
| 1-2
|
≥0.05
| 1.5-3
| 1.5
| 1550×780×1530
| 610
|
|
|
| <10
| 2-3
| 2.5-5
| 2.2
| 2270×1110×1890
| 900
|
|
|
| <10
| 2-4
| 5-10
| 3
| 3225×1550×2050
| 1640
|
|
|
| 12-30
|
50-125
| <10
| 3-6
| 7.5-15
| 5.5
| 2745×2000×3030
| 3085
|
|
|
| 25-57
| <25
| 4-8
| 8-20
| 7.5
| 4240×1990×2750
| 3098
|
|
|
| 25-57
| <25
| 4-8
| 8-20
| 4×2
| 4240×1990×2750
| 3500
|
|
|
| 12-30
| <10
| 3-6
| 12-25
| 7.5
| 3600×2000×2600
| 4500
|
Processing details
Application
