Changtong Semi-Conductor Bar Cutting Machine for Efficient Energy Solutions

Product Description

Equipment use: Purpose-built for optimal cutting efficiency, this model caters to customers' needs with precision. Featuring a substantial roller length of 690mm, its table dimensions are 170/145mm*690mm*160mm*2 version. It is adept at slicing products with thicknesses ranging from 0.3mm to 65mm.
CHTXQ-690F Double Plate Multi-Wire Cutting Machine: Discover the Unparalleled Product Features
1. The cutting-edge design incorporates four motors that independently power the rollers, transforming each into a drive shaft. This innovative feature drastically reduces steel line wear, enhancing roller longevity. Additionally, the roller bracket's processing center molding guarantees precision with spindle installation coaxiality.
2. Elevate your cutting experience with the optional LED display, offering crystal-clear, intuitive cutting data visibility.
3. Experience effortless operation with materials being cut from the bottom up under the table, ensuring seamless loading and unloading.
4. Superior versatility is achieved with two variations: the high-speed machine outpaces ordinary models with superior line speed and cutting efficiency, making it ideal for utilizing thinner diamond lines when cutting the same material.
5. The cutting table's transverse movement allows for back-and-forth motion, enabling the ability to cut tiles with precision and perform single-line cutting effortlessly.
6. Maximize your productivity with an expansive loading area—170/145mm*690mm*160mm*2 version—significantly boosting cutting efficiency.
7. Unmatched precision with spindle accuracy of ≤0.01mm, complemented by patented structure dust (Patent No. ZL201320681902.7) for stable operation and easy disassembly.
8. Simplify operations with user-friendly features: an automatic lifting shield, fully expanded workbench, and hassle-free material and roll handling.

	unit	parameter
Maximum Worksize	mm	170/145*690*160*2
cutting thickness	mm	0.6~65
running speed	m/min	0~2200
Table lift stroke	mm	220
Table cutting feed speed	mm/hour	0.1~100
The amount of wire output from the supply wheel	Km	30(φ0.2diamond wire)
Diamond diameter	mm	φ0.06~φ0.35axle
Roller outside diameter*number of axles	mm	φ155/φ180*690*4
boundary dimension	mm	≈1830*2800*2650
machine weight	Kg	6500~115000
power		AC380V/50HZ three-phase four-wire
Total machine power rating	Kw	54 above

This double-station, multi-wire cutting marvel employs diamond wire for impeccable product processing, accommodating two plates at once. With a robust 690mm roller length and an expansive maximum cutting area of 220mm*690mm*160mm*2 version, it ingeniously utilizes a rotary tool holder function. The cutting blade accommodates thicknesses from 0.5mm to 65mm, offering both single and multi-line cutting capabilities, ideal for batch processing of hard, brittle materials into straight sheets.
Presenting a breakthrough multi-line cutting solution, this model employs diamond line technology. With a 570mm roller length and a spacious maximum cutting area of 220mm*570mm*160mm, it revolutionizes cutting processes. Its rotary tool holder accommodates product thicknesses from 0.3mm to 65mm, deftly slicing open hard and brittle materials for mass straight sheet processing.
Tailored for precision, this compact multi-line cutting machine with diamond line technology offers versatility with single and double station models. Optimized for small batch straight sheet processing, it ensures effortless product specification changes. Accommodating cutting sheet thicknesses of 0.5mm to 30mm, it efficiently executes both single and multi-line cutting, perfect for small batch processing of hard and brittle materials.
>Stable Wire Web Control: Superior accuracy and rigidity are achieved through the innovative cone-positioned structure of the rollers and wire spools, minimizing wire web shaking.
The rollers and wire spools adopt a cone-positioned structure with unmatched accuracy and rigidity, expertly controlling wire web vibration.
>Optimized Pulley System: The meticulously designed 8-pulley system minimizes diamond wire torsion and tension fluctuations while significantly reducing the wire breakage rate.
A state-of-the-art 8-pulley design minimizes diamond wire torsion, tension fluctuations, and wire breakage rates, ensuring seamless performance.
>Easy Wire Winding: The wire pay-off wheel showcases a standard universal spool (PV600 reinforced I-wheel), eliminating the need for rewinding.
Featuring a standard universal spool (PV600 reinforced I-wheel), the wire pay-off wheel streamlines operations by eliminating the need for rewinding.
>Safety Guarantee: Operate with confidence as the main door, equipped with an electric safety device, can be effortlessly raised and lowered.
The main operation door is equipped with an electric raise-and-lower function, ensuring safety with its reliable safety device.
>Wire Break Memory System: Seamlessly manage wire operations with the innovative wire break memory system.
>Easy Operation: The cutting room offers unparalleled convenience with access from three sides, simplifying both operation and maintenance.
The cutting room's open design on three sides makes operations and maintenance effortlessly straightforward.

---
