E-Start Walking Tractor with 12HP Diesel Engine for Export

Product Description

1) good for dry field working
2) it can drive many implements, such as rotary tiller, rice and wheat harvester, trailer,plough, flail mower,ditcher,pump,corn seeder, peanuts seeder, etc.
3) more than 30 years technology and design, quality is good.

Mode	SX-8	SX-10	SX-12	SX-15	SX-18	SX-20
Power	8HP	10HP	12HP	15HP	18HP	20HP
Structure weight(kg)	270	290	300	480	480	480
Overall dimensions (L*W*H)	2120x 840 x 1160			2220x 1250 x 1220
Wheel track( mm)	680-740
Engine Type	Single cylinder,horizontal,4 stroke
Tire size	6.00-12( w-tire)			6.00-16( w-tire)
Gearbox style	main transmission and vice- transmission , 6 forward gears, 2 reverse gear full power shift. (3 + 1)×2 composition formula circular gear wheel column.
Clutch style	riple-plate,single-action,standard,dry-friction,long engaging friction
Min Ground Distance
Transmission	two belt			three belt
Rated Speed(r/min)	2200
Drivetrain final drive	single-stage spur gear circle column wheel drive
The fuel tank volume (L)	11			13
Engine lubricating oil (L)	1.5-2			2.5-3.2
Gearbox lubricants (L)	3-3.3			3-3.3
The cooling water injection amount (L)	12-13			13.5-15
Basic	Basic

Q1.Are you factory or trading company?
A: We are factory, our factory located in weifang city.
Q2.How about the working life of your walking tractor?
A: Accordingly to the feedbacks from our customers, our walking tractor can be used for about 5 to 10 years. The quality of our tiller is very good, so do not worry.
