Sunpal Home off Grid Hybrid Full Set 240V 3kw 5kw 10kw Solar Energy System

US$0.40-1.20 3,000 Watts (MOQ)

Basic Info.

Model NO.
SP10KW3-HY
Certification
ISO, CE
Application
Home
Specification
Normal, Solar Panels, Solar Inverter, Solar Battery,
System Type
Hybrid Solar PV System
Solar Panel Type
Monocrystalline Silicon, Polycrystalline Silicon
Battery Type
Lead-Acid, Lithium Ion, Lithium
Controller Type
MPPT
Mounting Type
Ground Mounting, Roof Mounting
Mounting System
Pitched Roof for Standards
Solar Panels Warranty
25years
Load Power (W)
3 5 8 10 Kw
Output Frequency
50/60Hz
DC Disconnect Switch
1000VDC 16A
AC Disconnect Switch
1000VDC 63A
Output Voltage (V)
220V;380V/400V, 208V/230V/240V;380V/400V
Online Monitoring
WiFi/LAN/GPRS
Work Time (H)
Depend on Sunshine Duration
PV Tools
Wire Cable
Transport Package
Wooden Box Package by Sea
Trademark
Sunpal
Origin
China
HS Code
8501320000
Production Capacity
10000 Piece/Pieces Per Day

Packaging & Delivery

Package Size
230.00cm * 160.00cm * 60.00cm
Package Gross Weight
1280.000kg

Product Description

Product Description
What's included
Components SP3KW-HY SP5KW-HY SP5KW3-HY SP8KW3-HY SP10KW3-HY
410W Solar Panel 8 Piece 14 Piece 14 Piece 20 Piece 26 Piece
DC Isolation Switch 1 Set 2 Set 1 Set 2 Set 2 Set
Hybrid Inverter 3KW 5KW 5KW 8KW 10KW
Triple Power Battery 4.5 Kwh 4.5 Kwh 6.3 Kwh 6.3 Kwh 6.3 Kwh
AC Isolation Switch 1 Set 1 Set 1 Set 1 Set 1 Set
DC Cable 4mm2 100 Meters 200 Meters 200 Meters 200 Meters 200 Meters
MC4 Connector 10 Piece 10 Piece 10 Piece 20 Piece 20 Piece
Mounting System 1 Set 1 Set 1 Set 1 Set 1 Set
PV Tools 1 Set 1 Set 1 Set 1 Set 1 Se
Hybrid Solar System Configuration
Our Factory
Packaging & Shipping
Application
