Cryogenic Liquid CO2 Storage Tank for Industrial Use

Product Description

Product Description
Cryogenic Liquid Co2 Storage Tank Is For Double Wall, The Inner Material Adopted 16MnDR Stainless Steel,The Outer Material Using Q245R,Carbon Steel. It Conclude Vertical And Horizontal Structure, Adopt The Use Of Vacuum Powder Adiabatic, With The Advantage Of Compact Structure , Low Issuance Date,Small Footprint,Centralized Control, Safe,Reliable, Easy Operation And Maintenance. The Design Of The Shell And Support System Can Withstand The Relevant External Forces Produced During Manufacture, Transportation, Installation And Use. The Bottom Of The Cryogenic Tank Is Provided With a Complete Set Of Valves, Meters And Safety Devices For Operation. Technical Parameter:

Effective volume (m3)	Working pressure (MPa)	Demension (mm)	weight (Kg)	Working medium	Placement type
5	2.16	2000*2000*5130	4450	liquid carbon dioxide	vertical or horizontal
10		2100*2100*7170	6986
15		2500*2500*6912	8810
20		2500*2500*8756	11328
30		2900*2900*8875	17961
50		3200*3200*11300	26097
100		3500*3500*16870	49627

(Specific cryogenic liquid storage with given pressureand effective volume can be manufactured as customer required)

Structural features:
1.Compact structure, cover a small area.
2.Storage tank and supercharger is a closed system, The liquid or gas can be supplied externally without any additional energy, ensure the liquid or gas purity when discharge.
3.With the pressure adjusting device, the user according to the need to adjust the regulator T,You can discharge the required pressure of the liquid,pressure is stable, easy to operate.
4.Tank provided with a tanker filled joints, can shipping liquid to the vaporizers, tankers.
5.Insulation material perlite and sorbent of storage tanks have been special treatment, to make sure the storage tank have more longer vacuum life. At the same time the storage tank with Metal thermocouple regulation,you can measuring the interlining vacuum when needed.
Packaging & Shipping
1.20ft &40ft container
2.Nude packing or Seaworthy packing
3.Customer's Request
Our Services
Company Profile
F:Are you a manufacturer or a trading company?
Q:We are a cryogenic liquid storage tank manufacturer, producing industrial gas storage equipment and ancillary products, can provide you with a complete set of gas supply equipment.

F:How about the production scale of your company?
Q:CNCD company was founded in 2002, has a total of 5 subsidiaries, 4 production bases, a total area of more than 160 acres, the production plant of 60,000 square meters, more than 400 employees, has rich experience in design, production and export, products have been exported to 68 countries and regions.

F:Do your products meet international standards? What are the certifications?
Q:Our products are in full compliance with international standards and have been certified and certified by many international standards, including ASME,CE,ISO,CCS,BV, etc.

F:Can you provide drawings before delivery?
Q:Of course, we are always ready to provide you with the drawings of the products you need for confirmation.

F:Can I customize the products I need?
Q:Of course, if you think our regular product model does not meet your needs, you can contact us, we will customize the most suitable for your needs.

F:How to deal with the quality problem of the product after purchase?
Q:Our products are of good quality and usually there won't be any problems. However, in case of product problems, you can immediately contact us, we will provide you with remote guidance and replacement parts or other services.

---
