Industrial Morther Board Ec3-J19t-6CD8 Kiosk Motherboard

Product Description

Product Configuration Product Characteristics
Support Baytrail Processor J1900 Onboard VGA/HDMI/LVDS Display Built-in HD Graphics card, 4K Display Integrated ALC662 Channel
Built in 1*Mini PCIe/ 2* SIM Expansion slot Support 4G/Wifi
Built in 1*Msata 1*SATA2.0 Support 1*USB 3.09*USB2.0
Support 6*COM (COM2 Supports 232/485,COM1
Supports TTL/232)
DC+2*PIN9~24V
Specification
Support Baytrail Processor J1900 Onboard VGA/HDMI/LVDS Display Built-in HD Graphics card, 4K Display Integrated ALC662 Channel
Built in 1*Mini PCIe/ 2* SIM Expansion slot Support 4G/Wifi
Built in 1*Msata 1*SATA2.0 Support 1*USB 3.09*USB2.0
Support 6*COM (COM2 Supports 232/485,COM1
Supports TTL/232)
DC+2*PIN9~24V

Processor	Support Baytrail J1900/J1800/N2807 Processor
Chipest	Intel J1900/J1800/N2807
GPU	Intel CPU Built in Display Core
Display output	VGA,HDMI,LVDS
Memory	1*SO-DIMM,DDR3L 1333MHz ,8GB
Audio	Onboard Realtek ALC662 HD
Network	Onboard 2*Intel 82583V Gigabit LAN
Storage	1*SATA2.0 1* MINI-SATA
Expansion Slot	1*MINI-PCIE(for WIFI ) 2*SIM(External Lead)
USB	1*USB3.0 9*USB2.0
COM	6*COM (Need to be extended)(COM2 Supports 232/485,COM1 Supports TTL/232)
Rear I/O	1*USB3.0 1*USB2.0 1*VGA 1*HDMI 2*LAN 1*DC 1*AUDIO
Internal I/O	4*F-USB2.0 PIN(Could be extended 8*USB2.0) 6*COM-SET PIN 6*COM PIN 1*LVDS PIN 1* PS/2 PIN 1*F_AUDIO PIN 1*F_PANEL PIN 1*AUTO-ON PIN 1*SYS-FAN PIN 1*SATA-PWR PIN 1*SPEAKER PIN 1*JME PIN 1*J485 PIN 1*GPIO PIN
BIOS	AMI BIOS
power supply	DC+2*PIN9~24V power supply
Cooling System	Comes with CPU cooler
Operating Humidity	-10~60ºC;0% ~ 95% Relative Humidity,Non- condensing
Form Factor	146X102MM

Detailed Photos
