| US$256,000.00 | 1 Piece (MOQ) |
| Technical specification | FRT-T130 | FRT-T160 | FRT-T200 | |
| Travel | ||||
| XYZW axis travel (worklable left and right movement) | mm | X:(4000-6000) Y:(2000-3000) Z:800 W:700 | X:(6000-8000) Y:(2000-3000) Z:1000 W:1000 | X:(8000-10000) Y:(3000-4000) Z:1200 W:1200 |
| Distance of spindle nose andworking table surface | mm | 0-3000 | 0-3000 | 0-4000 |
| Guide rail | Two linear guide rail,one hardened rail | |||
| Work Table | ||||
| Table size | mm | Customization | ||
| The maximum load capacity of the worktable | T | 15/m^2 | ||
| Spindle | ||||
| The spindle taper (model, sleeve diameter) | BT50 | |||
| Thespindle motor power | kw | 26 | 35 | 45 |
| Spindle speed | rpm | 2000 | 2000 | 1500 |
| Accuracy | ||||
| Precision of position | mm | 0.01/1000 | ||
| Accuracy of repeated position | mm | ±0.01 | ||
| Size | ||||
| Netweight(approx.) | T | 55-70 | 90-130 | 125-165 |
